250V Circular Connector Offering Waterproof IP67 and Copper Alloy Contact Material Designed for Industrial Power Systems

Product Description:

The Circular Connector, featuring the JAE M120-55780 model, is a robust and versatile solution designed to meet the demanding requirements of various industrial and commercial applications. Renowned for its reliability and durability, this connector is a prime example of high-quality Circular Metal Connectors that deliver exceptional performance in challenging environments.

One of the standout features of the JAE M120-55780 Circular Connector is its ability to operate efficiently within a wide temperature range of -25℃ to +85℃. This makes it suitable for use in environments where temperature fluctuations are common, ensuring consistent connectivity and minimizing the risk of failure due to thermal stress. Whether deployed outdoors or in industrial settings, this connector maintains its integrity and functionality under extreme conditions.

Designed as a multi-type connector, the Circular Connector is available in whip, puck, and panel configurations. This variety allows for flexible installation options tailored to specific application needs. The whip type offers ease of connection with pre-installed cables, the puck type provides a compact and secure interface, and the panel type ensures stable mounting on equipment or enclosures. This versatility is a significant advantage for engineers and designers seeking adaptable connection solutions.

Operating at a voltage of up to 250V, the JAE M120-55780 Circular Connector is well-suited for numerous electrical applications requiring reliable power transmission and signal integrity. Its robust construction supports efficient electrical performance, making it an ideal choice for systems where safety and stability are paramount.

Waterproofing is a critical attribute of this connector, which boasts an IP67 rating. This level of ingress protection guarantees that the connector is dust-tight and can withstand immersion in water up to 1 meter deep for 30 minutes without compromising its functionality. Such waterproof capabilities make it particularly useful in outdoor installations, marine applications, and other environments where exposure to moisture and contaminants is unavoidable.

In addition to its circular design, this connector aligns with the high standards set by other industry-leading products such as Heavy Duty Rectangular Connectors and Hirose Circular Connectors. While Heavy Duty Rectangular Connectors are known for their ruggedness and ability to handle high power and signal densities, the JAE M120-55780 Circular Connector offers the advantage of compactness and ease of use in confined spaces. Similarly, it shares the precision engineering and reliability characteristics that Hirose Circular Connectors are famous for, ensuring a dependable connection that withstands mechanical stress and vibration.

The combination of mechanical resilience, environmental protection, and electrical performance makes this Circular Connector an excellent choice for applications in transportation, industrial machinery, telecommunications, and outdoor equipment. Whether used in control panels, sensor connections, or power distribution systems, it provides a secure and stable interface that enhances overall system reliability.

In summary, the JAE M120-55780 Circular Connector embodies the essential qualities of top-tier Circular Metal Connectors. Its wide operating temperature range, multiple configuration types (whip, puck, panel), 250V operating voltage, and IP67 waterproof rating position it as a highly adaptable and robust connector solution. By integrating the best features found in Heavy Duty Rectangular Connectors and Hirose Circular Connectors, this product ensures superior performance and longevity in a compact and efficient design. For industries seeking dependable connectivity solutions that endure harsh environments, the JAE M120-55780 Circular Connector is an outstanding choice.

Features:

• Product Name: Circular Connector
• Shock Resistance: 980m/s², 6ms, Half Sine Wave, 6 Times
• Cable Outer Diameter: 2.6mm - 7.5mm
• Connector Types: Whip, Puck, Panel
• Operating Voltage: 250V
• Insulation Material: Thermoplastic
• Compatible with Half Moon Connector designs
• Supports Centronics Connector standards
• Suitable for Circular Connector Cable applications

Technical Parameters:

Applications:

The LP Circular Connector, model number LP-M8005, is a highly reliable and versatile connector designed to meet the rigorous demands of various industrial and commercial applications. Manufactured in China and certified under ISO-9001:2000, this product guarantees superior quality and consistent performance. With a supply ability of 100,000PCS and a minimum order quantity of 1000PCS, it is an ideal choice for large-scale projects requiring dependable Circular MIL Spec Connectors.

These Circular Plastic Connectors are engineered with a copper alloy contact material, ensuring excellent conductivity and durability. The contact resistance is maintained at a maximum of 5 OHMS, supporting stable electrical connections with an operating voltage of up to 250V. The connector’s length can be customized to suit specific installation requirements, providing flexibility in various design scenarios. Connector A is compatible with JAE M120-55780, which further enhances its adaptability in military and industrial environments.

This circular connector is particularly suitable for applications in aerospace, military, automotive, and telecommunications industries where robust and secure connections are critical. Its sturdy construction and standardized specifications make it an excellent choice for Circular MIL Spec Connectors used in harsh environments that demand resistance to vibration, moisture, and temperature fluctuations. The LP-M8005 model is also widely used in manufacturing equipment, industrial machines, and control systems, where reliable electrical connections are essential for operational safety and efficiency.

Packaging options include tube and tray formats, ensuring safe handling and ease of installation. Customers benefit from a competitive price point of $0.03 per unit and flexible payment terms such as T/T, Western Union, and L/C. Delivery is prompt, with an estimated lead time of 7 to 10 days, making it suitable for projects with tight schedules.

In summary, the LP Circular Plastic Connector LP-M8005 combines high performance, customizable features, and cost-effectiveness, making it a preferred solution for those seeking dependable Circular MIL Spec Connectors. Whether used in defense applications, industrial automation, or communication systems, these connectors provide secure, low-resistance connections that enhance overall system reliability.
