25C to 85C Circular Connector JAE M12055780 Black Robust Electrical Connector Suitable for Harsh Industrial Environments

Product Description:

The Circular Connector is an essential component designed to provide reliable and secure electrical connections in a variety of applications. Featuring a break-away locking type, this connector ensures easy and efficient disconnection when necessary, enhancing both safety and convenience for users. The break-away locking mechanism is engineered to prevent accidental disconnections while allowing quick release when required, making it ideal for environments where dependable connectivity and rapid maintenance are critical.

This Circular Electrical Connector is available in multiple configurations, including whip, puck, and panel types, offering versatility to meet diverse installation needs. The whip type is perfect for flexible wiring solutions, the puck type provides compact and robust connectivity, and the panel type allows for secure and stable mounting on equipment or enclosures. Each type is thoughtfully designed to deliver optimal performance and adaptability, catering to various industrial and commercial applications.

At the heart of this connector lies the 8-pin Male Solder Cup connector type, which facilitates straightforward and secure wiring connections. The solder cup design simplifies the termination process by allowing wires to be easily soldered to the connector pins, ensuring a strong and reliable electrical connection. This design is especially beneficial in environments where vibration or movement could otherwise compromise the integrity of the connection.

The mounting type for this Circular Connector is panel mount, which provides a sturdy and secure installation method. Panel mounting ensures that the connector remains firmly attached to the equipment or enclosure, reducing the risk of disconnection or damage during operation. This mounting style is widely used in both industrial and military applications due to its reliability and ease of integration into existing systems.

Constructed from high-quality copper alloy contact material, this Circular Electrical Connector guarantees excellent electrical conductivity and corrosion resistance. Copper alloy contacts are known for their durability and ability to maintain low contact resistance over extended periods, which is crucial for maintaining signal integrity and power transmission efficiency. The use of copper alloy also enhances the connector’s performance in harsh environments, providing long-term reliability and minimizing maintenance requirements.

Moreover, this product falls under the category of Circular MIL Spec Connectors, meaning it meets stringent military specifications for performance, durability, and environmental resistance. MIL Spec connectors are designed to operate reliably under extreme conditions, including exposure to moisture, vibration, temperature fluctuations, and mechanical stress. This makes the Circular Connector an ideal choice for defense, aerospace, and other demanding sectors where failure is not an option.

In summary, this Circular Connector combines a break-away locking mechanism with versatile types such as whip, puck, and panel, featuring an 8-pin Male Solder Cup connector type and panel mounting configuration. Its copper alloy contact material ensures superior electrical performance and durability, while compliance with MIL Spec standards guarantees robust operation in challenging conditions. Whether for industrial machinery, military equipment, or aerospace applications, this Circular Electrical Connector provides a dependable and high-quality solution for your connectivity needs.

Features:

• Product Name: Circular Connector
• Operating Voltage: 250V
• Contact Material: Copper Alloy
• Length: Customize according to requirements
• Mounting Type: Panel Mount
• Connector Type: 5-pin Female Solder Cup
• High-quality Electrical Connector suitable for various applications
• Durable Circular Connectors designed for reliable performance
• Compatible with Hirose Circular Connectors standards

Technical Parameters:

Applications:

The LP Circular Connector, model LP-M8011, is a highly reliable and versatile electrical connector designed to meet the demanding requirements of various industries. Manufactured in China and certified with ISO-9001:2000, this circular connector ensures top-notch quality and performance. With a waterproof rating of IP67, it is perfectly suited for applications where moisture resistance is critical, such as outdoor installations and harsh environments.

These circular plastic connectors are widely used in electrical and electronic systems requiring secure and stable connections. The 5-pin female solder cup connector type allows for easy wiring and ensures a robust electrical connection, making it ideal for industrial automation, machinery, and control systems. Its ability to operate efficiently within a temperature range of -25℃ to +85℃ further expands its usability in both cold and hot climates.

The LP-M8011 connector comes in various types including whip, puck, and panel configurations, offering flexibility for different installation scenarios. Its customizable length feature allows users to adapt the connector to specific project requirements, enhancing convenience and reducing the need for additional adapters or modifications. This makes it an excellent choice for applications such as robotics, transportation, and renewable energy systems where precise and secure connections are essential.

With a supply ability of 100,000 pieces and a minimum order quantity of 1000 pieces at an attractive price of 0.03 USD per unit, this electrical connector is suitable for large-scale manufacturing and distribution. Packaging options include tube or tray formats, ensuring safe transport and easy handling. Delivery time ranges from 7 to 10 days, and flexible payment terms like T/T, Western Union, and L/C accommodate various business preferences.

In summary, the LP Circular Plastic Connectors LP-M8011 are ideal for a wide range of electrical connector applications, providing durability, waterproof protection, and adaptability. Whether used in industrial control panels, outdoor lighting systems, or communication equipment, these connectors ensure reliable performance and long service life under challenging conditions.

Customization:

Introducing the LP Circular Connector model LP-M8011, a high-quality Connector Accessory designed for reliable and durable performance. Manufactured in China and certified under ISO-9001:2000, this Hermetic Connector ensures superior quality and stringent standards compliance.

With a mounting type of Panel Mount and gold-plated contacts, the LP-M8011 provides excellent conductivity and corrosion resistance. The connector is equipped with Connector A: JAE M120-55780 and uses thermoplastic as the insulation material, offering durability and stability across a wide operating temperature range of -25℃ to +85℃.

Ideal for various applications requiring robust Connector Accessories, this product is available with a minimum order quantity of 1000 PCS at a competitive price of $0.03 per unit. Packaging options include Tube or Tray to suit your logistics needs.

Our supply ability reaches up to 100,000 PCS with a delivery time of 7 to 10 days. Payment terms are flexible, accepting T/T, Western Union, and L/C, ensuring smooth and convenient transactions.

Choose the LP-M8011 Circular Connector for your next project and benefit from our exceptional Product Customization Services tailored to meet your specific requirements in Connector Accessories and Hermetic Connector solutions.

Support and Services:

Our Circular Connector product is designed to provide reliable and efficient connectivity solutions for a wide range of applications. For technical support, our team of experts is available to assist you with installation, troubleshooting, and maintenance to ensure optimal performance.

We offer comprehensive services including product selection guidance, customization options, and compatibility checks to meet your specific requirements. Detailed technical documentation, including datasheets and user manuals, is available to facilitate proper use and integration.

In addition, we provide repair and replacement services to minimize downtime and extend the lifespan of your connectors. Our commitment to quality and customer satisfaction ensures that you receive prompt and effective support throughout the product lifecycle.

For any technical inquiries or service requests related to the Circular Connector, please refer to the support resources provided with your product or visit our official website for additional information and updates.

Packing and Shipping:

Our Circular Connectors are carefully packaged to ensure maximum protection during transit. Each connector is individually wrapped in anti-static material and placed in a sturdy, cushioned box to prevent damage from shocks and vibrations.

The packaging includes clear labeling with product specifications, batch number, and handling instructions to facilitate easy identification and safe handling.

For shipping, we use reliable carriers with tracking options to ensure timely and secure delivery. Orders are processed promptly, and customers receive confirmation and tracking information once the product is dispatched.

We also offer customized packaging solutions upon request to meet specific shipping requirements or branding needs.
