Phosphor Bronze Female Header Connector Featuring PA6T Standard Strong Contact Material Ideal for Circuit Board Assembly

Product Description:

The Female Wire Header Connector is a versatile and reliable component designed to meet a wide range of electronic and electrical connection needs. Available with pin counts ranging from 2 to 40 pins, this connector provides flexibility for various applications, whether in compact devices or larger assemblies requiring multiple connections. Its design ensures secure and stable connections, making it an essential part of any wiring or circuit assembly.

One of the standout features of the Female Wire Header Connector is its impressive withstanding voltage rating of AC 500V. This high voltage tolerance ensures safety and reliability in environments where voltage fluctuations or spikes might occur, protecting both the connector and connected devices. This makes the connector suitable for industrial, automotive, and consumer electronics applications where durable electrical performance is critical.

The connector is available in multiple plastic heights, including 2.0mm, 3.12mm, 4.3mm, 4.5mm, 5.0mm, 5.9mm, 6.35mm, 7.1mm, and 8.5mm, allowing users to select the appropriate size for their specific application. This range of heights ensures compatibility with various board layouts and mechanical requirements, facilitating easy integration into diverse designs. Whether space-saving or requiring higher clearance, this connector offers the right fit.

Constructed using high-quality insulator materials such as Polyester (UL94V-0), LCP (Liquid Crystal Polymer), Nylon, and PA6T (also UL94V-0 rated), the Female Socket Header Connector guarantees excellent electrical insulation and mechanical strength. These materials are known for their flame-retardant properties, durability, and resistance to heat and chemicals. The UL94V-0 rating indicates that the materials are self-extinguishing and meet stringent safety standards, adding an extra layer of security and reliability to the product.

The combination of these advanced insulator materials ensures that the Female Wire Header Connector is not only robust but also capable of maintaining stable performance under harsh conditions. Whether exposed to high temperatures, mechanical stress, or chemical exposure, the connector maintains integrity, preventing failures and ensuring long-term operation.

Designed for ease of use, the Female Wire Header Connector features a well-engineered interface that allows for quick and secure mating with corresponding male headers or wire harnesses. This ease of connection and disconnection is vital for applications requiring maintenance or frequent assembly and disassembly. The connector’s precision manufacturing ensures a tight fit that minimizes signal loss and mechanical wear over time.

In summary, the Female Wire Header Connector is an ideal choice for engineers and designers seeking a dependable, high-performance female socket header connector. Its wide range of pin configurations, high withstanding voltage, multiple plastic height options, and superior insulator materials combine to offer a product that excels in safety, reliability, and versatility. Whether used in industrial controls, automotive electronics, communication devices, or consumer products, this connector provides consistent performance and peace of mind.

By choosing this Female Wire Header Connector, users benefit from a product that meets rigorous standards and adapts to various design requirements. Its robust construction and thoughtful design make it an indispensable component in modern electronic assemblies, ensuring secure electrical connections and longevity in service.

Features:

• Product Name: Female Header Connector
• Available Pins: 2 to 40 Pins
• Contact Plating: Gold (Au) or Tin (SN) over 40 microinches
• Operating Temperature Range: -40° to +105°
• Material: PA6T with 30% Glass Fiber
• Connector Types: Vertical, Right Angle, Surface Mount Technology (SMT)
• Row Options: Single Row, Double Row, Three Rows
• Includes Female Header Pin Connector, Female Inline Header Connector, and Female PCB Header Connector variations

Technical Parameters:

Applications:

The LP-FH044 Female Header Connector, manufactured by the reputable brand LP in China, is a versatile and reliable component widely used in various electronic and electrical applications. Certified under ISO-9001:2000, this Female Socket Header Connector is designed to meet high-quality standards, ensuring durability and consistent performance. With a robust construction utilizing PA6T reinforced with 30% glass fiber and contact materials made from high-quality phosphor bronze or brass, it offers excellent mechanical strength and conductivity. The connector operates efficiently within a working temperature range of -40°C to +105°C, making it suitable for environments with fluctuating temperatures.

In industrial and consumer electronics, the Female Wire Header Connector is commonly used for connecting wires to printed circuit boards (PCBs), enabling secure and stable electrical connections. It is ideal for applications requiring frequent mating and unmating, such as in communication devices, instrumentation, automotive electronics, and home appliances. Its maximum processing temperature of 230°C for 30-60 seconds (and 260°C for 5 seconds) ensures compatibility with standard soldering processes, which is essential for assembly lines and manufacturing environments.

The Female Header Pin Connector is also highly valued in prototyping and development scenarios where modular and flexible connections are crucial. Its low contact resistance of 30mΩ max guarantees minimal signal loss, making it suitable for data transmission and power supply applications. Additionally, its packaging options—including reel, tube, tray, and polybag—offer convenience and adaptability for different production and inventory needs. With a supply ability of 100,000PCS and a minimum order quantity of 1000PCS, the LP-FH044 is an excellent choice for mass production.

Furthermore, the LP-FH044 Female Header Connector's competitive pricing at 0.0001 (per unit) combined with flexible payment terms such as T/T, , and L/C, and a delivery time of 7 to 10 days, makes it an attractive option for manufacturers and suppliers seeking cost-effective and efficient solutions. Whether you are designing new electronic devices or maintaining existing equipment, this connector provides a reliable and high-performance interface for various applications, ensuring long-term stability and performance.

Customization:

LP brand offers high-quality Female Inline Header Connector, model number LP-FH044, manufactured in China with ISO-9001:2000 certification. Our Female Electrical Header Connector is designed with superior insulator materials including LCP, Nylon, and PA6T (UL94V-0), ensuring durability and safety. The Female Pin Header Connector features contact materials made of Phosphor Bronze or Brass, with a contact resistance of 30mΩ max, providing reliable electrical performance.

This product supports mounting types of Through Hole and SMT, with contact plating options of Au or SN over 40n to ensure excellent conductivity and corrosion resistance. We offer flexible packaging options including Reel, Tube, Tray, and Polybag to meet diverse customer needs.

The minimum order quantity is 1000PCS, priced competitively at 0.0001 per unit. Our supply ability reaches up to 100,000PCS, and delivery time ranges from 7 to 10 days. Payment terms include T/T, , and L/C for your convenience.

Trust LP’s Female Inline Header Connector for your electronic projects, combining quality, reliability, and efficient customization services to meet your exact requirements.
