40 C to 105 C Female Socket Header Connector Through Hole SMT Mounting Type Suitable for Electronic Device Manufacturing

Product Description:

The Female Header Connector is an essential component widely used in electronic assemblies for establishing reliable electrical connections between printed circuit boards (PCBs) and other electronic modules. This versatile connector is designed to provide secure and efficient interfacing, making it a popular choice in various applications ranging from consumer electronics to industrial equipment. The Female Header Connector, also commonly referred to as the Female PCB Header Connector or Female Pin Header Connector, is engineered to meet stringent quality and performance standards, ensuring durability and consistent electrical conductivity.

One of the key features of this Female Socket Header Connector is its ability to withstand high processing temperatures. It supports a maximum processing temperature of 230℃ for 30 to 60 seconds, which is ideal for soldering processes without compromising the integrity of the connector. Additionally, it can tolerate brief exposure to temperatures as high as 260℃ for up to 5 seconds, allowing flexibility in various assembly and manufacturing environments. This thermal resilience ensures that the connector maintains its mechanical and electrical properties even after extensive soldering cycles.

The Female Header Connector comes in multiple pitch sizes to accommodate different design requirements. Available pitch options include 0.8mm, 1.0mm, 1.27mm, 2.0mm, and 2.54mm, providing designers with the flexibility to select the most suitable spacing between pins for their specific applications. This range of pitch sizes makes the connector compatible with a broad spectrum of PCBs, allowing for compact designs as well as larger, more robust connections depending on the project needs.

Constructed with high-quality contact materials, the Female PCB Header Connector ensures excellent electrical conductivity and corrosion resistance. The contacts are made from either phosphor bronze or brass, both of which are known for their superior mechanical strength and reliable performance in electrical applications. Phosphor bronze offers excellent fatigue resistance and good conductivity, while brass provides a balance of strength and electrical performance. These materials contribute to the longevity and reliability of the Female Pin Header Connector in demanding operational environments.

The current rating of the Female Socket Header Connector is 1.5 Amps, making it suitable for a wide range of low to moderate power applications. This current capacity ensures that the connector can safely handle typical electronic signals and power loads without overheating or experiencing performance degradation. Whether used in signal transmission or power delivery, the connector delivers consistent and stable electrical connections.

Furthermore, the pin material used in this Female Header Connector is also available in phosphor bronze or brass, matching the contact material options. This choice of materials for both pins and contacts enhances the overall conductivity and mechanical stability of the connector, ensuring that electrical connections remain intact even under mechanical stress or vibration.

In summary, the Female Header Connector is a highly reliable and versatile component designed to meet the needs of modern electronic assemblies. Its ability to withstand high processing temperatures, availability in multiple pitch sizes, use of premium contact and pin materials, and a current rating of 1.5 Amps make it an excellent choice for engineers and designers seeking dependable Female PCB Header Connectors. Whether referred to as a Female Pin Header Connector or Female Socket Header Connector, this product ensures secure, efficient, and long-lasting connections in a variety of electronic applications.

Features:

• Product Name: Female Header Connector
• Material: PA6T+30% Glass Fiber for enhanced durability
• Contact Material: High-quality Copper Alloys ensuring excellent conductivity
• Maximum Processing Temperature: 230℃ for 30-60 seconds, 260℃ for 5 seconds
• Standard Compliance: PA6T
• Contact Resistance: 30mΩ Max for reliable electrical performance
• Compatible as a Female Board Header Connector
• Ideal Female Header Pin Connector for various electronic applications
• Reliable Female Electrical Header Connector suitable for circuit board connections

Technical Parameters:

Applications:

The LP Female Header Connector, model number LP-FH039, is a highly versatile and reliable component designed and manufactured in China, catering to a wide range of electronic applications. Certified under ISO-9001:2000, this product guarantees superior quality and durability, making it an ideal choice for both industrial and consumer electronics. Available with a minimum order quantity of 1000PCS and competitively priced at 0.0001 per unit, the LP Female Header Connector is perfect for large-scale production needs. Its packaging options include Reel, Tube, Tray, and Polybag, ensuring safe and convenient handling during transportation and storage.

This Female Header Pin Connector is designed for various mounting types, including Through Hole and Surface Mount Technology (SMT), offering flexibility in PCB design and assembly. The connector is available in multiple configurations such as Vertical, Right Angle, Single Row, Double Row, and Three Rows, with pitch options ranging from 0.8mm to 2.54mm. This broad spectrum of specifications allows engineers and designers to select the optimal connector type to suit their specific project requirements. Additionally, plating options of Gold or Tin provide excellent conductivity and corrosion resistance, enhancing the connector's performance and longevity.

In practical application scenarios, the LP Female Header Socket Connector is widely used in telecommunications, computer hardware, consumer electronics, automotive electronics, and industrial machinery. Its reliable electrical connection and robust design make it suitable for high-density PCB layouts in servers, networking equipment, embedded systems, and IoT devices. The Female Wire Header Connector variant is also ideal for wire-to-board connections, facilitating easy and secure interfacing between cables and circuit boards.

Manufacturers and electronic assemblers appreciate the LP Female Header Connector for its consistent quality, timely delivery within 7 to 10 days, and flexible payment terms including T/T, Western Union, and L/C. With a supply capacity of 100,000PCS, LP ensures dependable availability to meet urgent production demands. Supported by Openresty server technology, the ordering process is streamlined for efficiency and customer convenience.

Overall, the LP-FH039 Female Header Connector series stands out as an essential component for various electronic design and manufacturing occasions, providing excellent electrical performance, mechanical stability, and adaptability across multiple industries and applications.

Customization:

Our LP brand Female Header Connector, model number LP-FH039, is a high-quality Female Wire Header Connector designed and manufactured in China. Certified with ISO-9001:2000, this Female PCB Header Connector guarantees reliable performance and durability. Made from PA6T material reinforced with 30% glass fiber, it ensures excellent strength and stability under various operating conditions.

This Female Connector Header Pin features both Through Hole and SMT mounting types, offering versatile installation options. It has a maximum contact resistance of 30mΩ and can operate efficiently within a temperature range of -40° to +105°. The product is available in packaging options including Reel, Tube, Tray, and Polybag, catering to different customer preferences.

With a minimum order quantity of 1000PCS and a competitive price of 0.0001 per unit, we provide a supply ability of up to 100,000PCS. Delivery time is typically 7 to 10 days, and we accept payment terms including T/T, Western Union, and L/C.

Choose our LP-FH039 Female Wire Header Connector for your projects to ensure high quality, reliable connections, and excellent service.
