Card retention force 10-20N SD Holder Connector featuring Tin Lead 100u Plating and Gold Plated Contact Plating suitable for device connections

Product Description:

The SD Holder Connector is a high-quality component designed to provide reliable and efficient connectivity for Secure Digital (SD) cards. Ideal for a broad range of applications, this connector is specifically engineered to accommodate SD memory cards with precision and durability. It serves as an essential interface in devices requiring a Secure Digital Card Slot, ensuring seamless data transfer and secure card retention.

One of the standout features of this SD Holder Connector is its card push insertion and out force, which ranges between 0.7 to 1.20 kgf. This specification ensures that the SD card can be inserted and removed smoothly without excessive force, providing a balance between secure card retention and user convenience. The comfortable insertion force reduces wear on both the card and the connector, enhancing the longevity of your device's Secure Digital Card Reader system.

The connector is designed to operate efficiently within a wide temperature range, from -40°C to 90°C. This broad operating temperature range makes it suitable for use in a variety of environments, from extreme cold conditions to high-temperature applications. Whether your device is exposed to outdoor elements or industrial settings, this SD Memory Slot Connector maintains stable performance and reliability, protecting your data and connection integrity.

Constructed with premium copper alloy contacts, the SD Holder Connector ensures excellent electrical conductivity and corrosion resistance. Copper alloy provides a robust and durable interface that supports consistent signal transmission, which is critical for high-speed data communication in Secure Digital Card Readers. The high-quality contact material also contributes to the overall durability and lifespan of the connector, reducing maintenance needs and potential failures.

This SD Holder Connector also features an integrated card detect switch, a crucial component for modern digital devices. The card detect switch automatically senses the presence or absence of an SD card, enabling the connected device to initiate appropriate actions such as mounting the card, starting data transfer, or safely ejecting the card. This functionality improves device usability, prevents data corruption, and enhances user experience by providing instant feedback when an SD card is inserted or removed.

Adding to its durability and safety, the connector is equipped with a slider made from high-temperature plastic rated UL 94V-0. This rating indicates excellent flame retardant properties, ensuring that the component meets stringent safety standards. The slider mechanism facilitates smooth card insertion and removal, while the use of high-temperature resistant plastic ensures that the connector remains stable and secure even under prolonged operational stress or elevated temperatures.

Overall, the SD Holder Connector is an essential component for any device requiring a Secure Digital Card Slot or a Secure Digital Card Reader. Its robust construction, combined with thoughtful design features such as the card detect switch and the high-temperature resistant slider, makes it an ideal choice for manufacturers and developers aiming to deliver reliable and user-friendly SD card interfaces. Whether used in consumer electronics, industrial equipment, or automotive applications, this connector guarantees performance, safety, and durability.

In summary, the SD Holder Connector offers a reliable solution for Secure Digital Card connectivity with its optimal insertion force, extensive operating temperature range, premium copper alloy contacts, built-in card detect switch, and a high-temperature plastic slider. This combination of features ensures that the connector not only meets but exceeds the demands of modern devices requiring Secure Digital Card Slots or Secure Digital Card Readers, making it a smart investment for durable and efficient SD card integration.

Features:

• Product Name: SD Holder Connector
• Spring Type: SWP
• Insulation Resistance: 1000 MΩ Minimum
• Contact Material: Copper Alloy
• Mating Cycles: 10,000 Insertions
• Contact Resistance: 40 Megohms Max
• Designed as an SD Card Interface Holder for reliable connectivity
• Functions as an SD Memory Slot Connector ensuring durability and performance

Technical Parameters:

Applications:

The LP-SD035 Secure Digital Holder Connector, manufactured by LP in China, is a highly reliable and durable component designed specifically for Secure Digital Card Readers. With ISO-9001:2000 certification ensuring its quality, this product meets the stringent standards required for modern electronic applications. Its robust construction, featuring stainless steel links, guarantees long-lasting performance even in demanding environments. The connector operates efficiently within a wide temperature range of -40°C to 90°C, making it suitable for various climates and operating conditions.

Ideal for embedded systems and consumer electronics, the LP-SD035 Secure Digital Holder Connector is widely used in devices that require secure and stable connections for Secure Digital Card Readers. Its excellent insulation resistance of 1000 MΩ minimum ensures signal integrity and protection against electrical interference, which is critical for reliable data transfer in applications such as portable media players, digital cameras, and other consumer gadgets. This product’s compliance with RoHS and REACH standards further highlights its environmental safety and suitability for global markets.

The product is packaged in reels, tubes, or trays, facilitating easy handling and integration into automated production lines. With a supply ability of 100,000 PCS and a minimum order quantity of 1000 PCS, manufacturers can efficiently source this Secure Digital Holder Connector for large-scale production. The competitive pricing of 0.0003 per piece, combined with flexible payment terms including T/T and L/C, makes it an economical choice for OEMs and electronic device manufacturers.

Delivery times are prompt, typically ranging from 7 to 10 days, ensuring that production schedules remain uninterrupted. The LP-SD035 is engineered to meet the needs of modern electronics, where secure and reliable card reading is essential. Whether used in consumer electronics or embedded systems, this Secure Digital Card Reader connector provides a dependable solution, improving device performance and user experience.

In summary, the LP brand’s Secure Digital Holder Connector LP-SD035 stands out as a high-quality, cost-effective component for Secure Digital Card Readers in various applications. Its durability, compliance with international standards, and excellent electrical properties make it an indispensable part of embedded systems and consumer electronic devices worldwide.

Customization:

Introducing the LP SD Holder Connector, model number LP-SD035, a high-quality Secure Digital Card Reader designed and manufactured in China. This SD Card Holder Assembly supports Micro SD, MINI SD, 4-in-1 (MS+SD+MMC+XD), and 3-in-1 configurations, making it a versatile SD Memory Slot Connector solution for various applications.

Certified with ISO-9001:2000 and compliant with RoHS and REACH standards, this product ensures reliable performance and environmental safety. The contacts are made from copper alloy with a thickness of 0.15mm, offering excellent conductivity and durability. The contact resistance is rated at a maximum of 40 Megohms, guaranteeing stable data transmission.

The SD Holder Connector comes in a sleek black color and is available in packaging options including reel, tube, and tray to meet different assembly needs. With a minimum order quantity of 1000PCS and a competitive price of 0.0003 per unit, it is ideal for large-scale production.

We offer a supply ability of 100,000PCS with a prompt delivery time of 7 to 10 days. Payment terms include T/T and L/C for your convenience. Choose the LP SD Holder Connector for a reliable, customizable Secure Digital Card Reader and SD Memory Slot Connector solution.

Support and Services:

Our SD Holder Connector product is designed to provide reliable and secure connections for SD cards in various electronic devices. For technical support, we offer comprehensive assistance including installation guidance, troubleshooting tips, and maintenance advice to ensure optimal performance.

Services include product configuration support, firmware updates when applicable, and compatibility consultations to help integrate the SD Holder Connector seamlessly into your projects. Our technical team is dedicated to resolving any issues promptly and effectively.

We recommend referring to the product manual for detailed instructions on proper handling and usage. Additionally, we provide resources such as FAQs and troubleshooting guides to assist users in resolving common issues independently.

For warranty information and repair services, please consult the documentation provided with your product. Our commitment is to deliver high-quality support and services to maximize the lifespan and functionality of your SD Holder Connector.

Packing and Shipping:

Product Packaging: The SD Holder Connector is carefully packaged in a sturdy, protective box to prevent any damage during transit. Each unit is individually sealed in an anti-static bag to safeguard against electrostatic discharge. The packaging includes foam inserts to securely hold the connector in place, ensuring it remains intact and free from scratches. Clear labeling and product information are printed on the box for easy identification.

Shipping: We offer reliable and fast shipping options worldwide. All orders are processed within 1-2 business days. The SD Holder Connector is shipped with tracking information provided to the customer for monitoring the delivery status. We use reputable courier services to ensure safe and timely delivery. International shipments may be subject to customs fees and import duties, which are the responsibility of the recipient.
