Overall insertion force 3.57kgf MAX Universal Serial Bus Connector dielectric withstanding AC 100V suitable for electronic device applications

Product Description:

The USB Connector is a high-performance and reliable solution designed to facilitate seamless connections between various electronic devices. As a crucial component in modern technology, this connector serves as a USB Peripheral Connection Interface, enabling efficient communication and power transfer between computers, peripherals, and external devices. Engineered to meet demanding standards, this USB Connector ensures durability, safety, and optimal performance for diverse applications.

One of the standout features of this USB Connector is its selective plating on the contacts. Selective plating enhances conductivity and corrosion resistance, providing a stable and long-lasting electrical connection. This careful plating process ensures that the contacts maintain their integrity even after repeated insertions and removals, a critical aspect for any External Device Connection Port that experiences frequent use.

The insulator material used in the connector is a blend of PBT (Polybutylene Terephthalate) and LCP (Liquid Crystal Polymer) with 30% glass fiber, complying with the UL94V-0 flammability standard. This combination offers exceptional mechanical strength, heat resistance, and flame retardance, guaranteeing safe operation under various environmental conditions. The robust insulator material not only protects the internal circuitry but also contributes to the overall structural stability of the Standard USB Plug Connector.

In terms of electrical performance, the USB Connector supports a contact current rating of 3.0A specifically for the VBUS pin and its corresponding ground (GND) pin, ensuring reliable power delivery to connected devices. For all other contacts, a minimum current rating of 0.25A is maintained to support signal integrity and communication functions. This differentiation in current ratings allows the connector to efficiently handle power and data transmission simultaneously without compromising safety or performance.

Data transfer speed is a critical factor for any USB interface, and this connector excels by supporting speeds of up to 10 Gbps, complying with the USB 3.1 standard. This high-speed capability makes it ideal for transferring large files, streaming high-definition video, or connecting high-bandwidth peripherals such as external hard drives and advanced input devices. Users can expect fast, reliable, and stable data communication, enhancing overall productivity and user experience.

Durability is another key attribute of this USB Connector, with an overall pull-out force rated at a minimum of 1.02 kgf. This pull-out force ensures that the connector remains securely attached during operation, preventing accidental disconnections and ensuring consistent connectivity. Whether used in consumer electronics, industrial equipment, or professional devices, this feature adds an extra layer of reliability to the External Device Connection Port.

Designed to function as a Standard USB Plug Connector, this product adheres to universal USB specifications, making it widely compatible with numerous devices and systems. Its construction and performance characteristics make it an excellent choice for manufacturers and users seeking a dependable USB Peripheral Connection Interface that supports high-speed data transfer, robust power delivery, and long-term durability.

In summary, this USB Connector combines selective contact plating, advanced insulator materials, precise current ratings, high-speed data transfer capabilities, and strong mechanical retention force to deliver an exceptional connection experience. Its role as an External Device Connection Port and Standard USB Plug Connector ensures versatility and compatibility across a wide range of applications, making it an indispensable component in today’s interconnected digital world.

Features:

• Standard USB Plug Connector suitable for various applications
• Supports multiple types: USB 2.0, USB 3.0, USB 3.1, Micro USB, and MINI USB
• Universal Serial Bus Connector ensuring compatibility across devices
• Dielectric withstanding voltage of AC 100V for reliable insulation
• Insulator material made from PBT or LCP+30% Glass Fiber with UL94V-0 flame retardant rating
• Current rating ranges from 1.5A up to 5A to support different power requirements
• Connector insertion force between 5 to 20N, tested at a maximum rate of 12.5mm per minute
• Designed as a USB Peripheral Connection Interface for seamless device connectivity

Technical Parameters:

Applications:

The LP brand USB Connector, model number LP-U035, is a high-quality High Speed USB Connector designed and manufactured in China, certified under ISO-9001:2000 standards. This product offers a reliable and efficient solution for various electronic devices requiring a robust External Device Connection Port. Its compact USB connection interface makes it ideal for modern devices where space-saving and performance are critical.

This USB connector is widely applicable in numerous occasions and scenarios. It is perfect for integration into laptops, desktops, tablets, and other consumer electronics that demand fast data transfer rates and stable connectivity. Due to its compact design, the LP-U035 is especially suitable for portable devices where minimizing the device footprint is essential without compromising on connection quality.

In industrial and commercial environments, the LP-U035 USB connector excels as a dependable port for connecting peripherals such as printers, scanners, external storage devices, and other USB-enabled equipment. The connector’s shell, made from copper alloy and steel, ensures durability and resistance to wear and tear, making it ideal for repeated use in high-traffic settings.

The LP-U035’s insulation impedance of 100MΩ minimum at 250V DC guarantees excellent electrical performance and safety, which is crucial for sensitive electronic applications. Additionally, the contact plating with selective plating and 1U plating enhances signal integrity and longevity, supporting consistent high-speed data transmission.

Manufacturers and assembly lines benefit from the recommended IR reflow process at 260°C for 3 to 5 seconds, ensuring reliable soldering and assembly. The product is packaged carefully in reels, tubes, or trays, catering to different production needs and facilitating smooth logistics. With a minimum order quantity of 1000PCS and a supply ability of 100,000PCS, this USB connector is suitable for both small and large-scale production runs.

The competitive pricing of $0.01 per unit, combined with flexible payment terms including T/T, Western Union, and L/C, makes the LP-U035 an attractive choice for manufacturers worldwide. Delivery within 7 to 10 days ensures timely fulfillment of orders, supporting tight production schedules.

Overall, the LP-U035 High Speed USB Connector serves as an essential component for any application requiring a reliable, compact, and fast USB connection interface, ensuring seamless communication between devices in a variety of usage scenarios.

Customization:

Introducing the LP USB Connector, model number LP-U035, a high-quality product originating from China and certified by ISO-9001:2000. Designed as a Universal USB Interface Connector, it ensures reliable USB Peripheral Connection Interface performance for various applications.

Our USB Data Transfer Connector boasts exceptional technical specifications, including a contact resistance of 40 milliohms max for VBUS and GND contacts, and 50 milliohms max for other contacts. The connector features a plating of 1 U and an insertion force ranging from 5 to 20N, tested at a maximum rate of 12.5mm per minute, ensuring ease of use and durability.

With an insulation resistance of at least 100 megohms and a durability rating of 10,000 cycles, the LP-U035 USB Connector guarantees long-lasting performance and stability for your USB connectivity needs.

We offer a minimum order quantity of 1000PCS at a competitive price of $0.01 per unit. Packaging options include Reel, Tube, or Tray to suit your logistics requirements. Our supply ability reaches up to 100,000PCS, with a delivery time of 7 to 10 days.

Payment terms are flexible, accepting T/T, Western Union, and L/C, making transactions smooth and convenient. Choose the LP-U035 USB Connector for reliable and efficient USB Peripheral Connection Interface solutions that meet your business demands.
