250V AC DC Voltage Rating IDC Socket BOX Header with PA6T UL 94V 0 Black Insulator and Insulation Displacement Contact Termination Method

Product Description:

The IDC Socket / BOX Header product is a highly reliable and versatile connector solution designed to meet the demanding requirements of modern electronic applications. Featuring an Insulation Resistance of 1000M Ohms minimum, this connector ensures excellent electrical isolation and minimal leakage current, making it ideal for environments where signal integrity and performance are critical. The product is engineered to provide robust and consistent connectivity across a wide range of applications, from consumer electronics to industrial equipment.

One of the standout features of this product is its wide range of available positions, accommodating from 2 to 40 pins. This flexibility allows designers and engineers to select the precise configuration needed for their specific application, whether it’s a compact device requiring just a few connections or a more complex system demanding multiple signal lines. The IDC Socket Connector Assembly is designed to facilitate quick and reliable wire termination, reducing assembly time and improving manufacturing efficiency.

In terms of electrical performance, the IDC Box Header Connector exhibits a maximum Contact Resistance of 20M Ohms, ensuring low resistance contacts and stable electrical connections throughout the product’s lifecycle. This characteristic is essential for maintaining signal clarity and preventing data loss or interference. Additionally, the Insulator material used in this connector is PA6T UL 94V-0 Black, a high-performance polyamide that offers excellent thermal stability, mechanical strength, and flame retardant properties. This makes the connector suitable for use in harsh environments where durability and safety standards are paramount.

The IDC Socket / BOX Header product is available in multiple pitch options, including 0.8mm, 1.0mm, 1.27mm, 2.0mm, and 2.54mm. These pitch variations provide great design flexibility, enabling compatibility with a broad array of printed circuit boards (PCBs) and other components. Whether the application requires a fine-pitch connector for space-saving designs or a standard-pitch solution for easier handling and assembly, this product line covers all these needs with precision and reliability.

As an Insulation Displacement Contact Socket, this connector simplifies the wiring process by allowing wires to be connected directly without the need for stripping insulation. This feature not only streamlines assembly but also enhances the durability and reliability of the electrical connection by minimizing potential points of failure. The IDC technology employed in this connector ensures a secure grip on the conductor, reducing the risk of loose connections and improving overall system reliability.

Overall, the IDC Socket Connector Assembly and IDC Box Header Connector represent an excellent choice for applications requiring a dependable, high-performance, and easy-to-assemble connection solution. Their combination of high insulation resistance, low contact resistance, durable materials, and flexible pitch options make them suitable for a wide range of industries and applications. Whether used in telecommunications, automotive electronics, industrial control systems, or consumer devices, these connectors deliver consistent performance and long-term reliability.

With their innovative design and robust construction, these connectors meet stringent quality standards and provide engineers with the confidence that their products will perform flawlessly in the field. The IDC Socket / BOX Header product line continues to be a preferred solution for professionals seeking a balance of electrical performance, mechanical strength, and ease of assembly in a compact and reliable package.

Features:

• Product Name: IDC Socket / BOX Header
• Type: Insulation Displacement Contact Socket
• Connector Style: Box Header IDC Connector
• Voltage Rating: 250V AC/DC
• Contact Resistance: 20M Ohms Max
• Number of Positions: 2 to 40
• Insulator Material: PA6T UL 94V-0 Black
• Current Rating: 3A Per Contact
• Durable and reliable Insulation Displacement Contact Socket design

Technical Parameters:

Applications:

The LP-BX029 IDC Socket / BOX Header, manufactured by LP in China, is a highly reliable Insulation Displacement Connector Socket designed for a wide range of electronic applications. Certified under ISO-9001:2000, this product ensures consistent quality and performance, making it an ideal choice for both industrial and consumer electronics. The IDC Socket Connector Assembly is engineered to provide secure and efficient connections with a current rating of 1.0 Amp, supporting operating temperatures from -65°C to +125°C. This robust temperature range makes it suitable for use in harsh environmental conditions, including automotive, telecommunications, and industrial control systems.

With a termination method based on Insulation Displacement Contact (IDC), the LP-BX029 facilitates quick and reliable wire termination without the need for stripping insulation, significantly reducing assembly time and improving productivity. It supports a versatile number of positions, ranging from 2 to 40, accommodating various wiring configurations and application requirements. The standard black color enhances compatibility with different design aesthetics and electronic setups, while its packaging options—Reel, Tube, Tray, and Polybag—offer flexibility for manufacturers in handling and inventory management.

The IDC Ribbon Cable Socket is extensively used in scenarios requiring fast, durable, and efficient cable connections, such as in computer motherboards, networking devices, and industrial equipment. Its compact design and ease of assembly make it perfect for mass production environments, with a minimum order quantity of 1000PCS and a supply ability of up to 100,000PCS. The product’s competitive price point of 0.0001 per piece, combined with delivery times of 7 to 10 days, ensures cost-effective procurement and timely project execution.

Payment terms including T/T, Western Union, and L/C provide convenient options for global buyers, enhancing the accessibility of the LP-BX029 IDC Socket Connector Assembly. Whether you are designing communication systems, embedded devices, or automated machinery, this IDC Socket offers dependable performance and efficient connectivity, making it an essential component in modern electronic assembly applications.

Customization:

Introducing the LP brand IDC Socket / BOX Header, model number LP-BX029, a high-quality IDC Cable Socket Connector manufactured in China. Certified with ISO-9001:2000, this product guarantees reliable performance and durability.

Our Box Header IDC Connector features Insulation Displacement Contact (IDC) termination method, ensuring secure and efficient connections with an insulation resistance of 1000M Ohms minimum. The product supports multiple pitch options including 0.8mm, 1.0mm, 1.27mm, 2.0mm, and 2.54mm, suitable for various applications.

The IDC Socket Connector Assembly is rated for a voltage of 250V AC/DC, making it ideal for a wide range of electronic devices. We offer flexible packaging options such as Reel, Tube, Tray, and Polybag to meet your specific needs.

With a supply ability of 100,000PCS and a minimum order quantity of 1000PCS, we ensure timely delivery within 7 to 10 days. Our competitive price of 0.0001 per unit, combined with flexible payment terms including T/T, Western Union, and L/C, makes the LP-BX029 the perfect choice for your IDC connection requirements.
