Phosphor Bronze Contact Material SD Holder Connector Providing 30-50N Card Insertion Force and 10 Mating Cycles Ensuring Electrical Contact

Product Description:

The SD Holder Connector is a highly reliable and durable component designed specifically for Secure Digital (SD) card applications. Engineered with precision, this connector serves as an essential interface in various electronic devices, ensuring secure and efficient data transfer between the SD card and the host system. Whether you are working on consumer electronics, embedded systems, or industrial equipment, the SD Holder Connector provides a robust solution for your SD card connectivity needs.

One of the most critical features of this SD Holder Connector is its shell, which is crafted from high-quality stainless steel with a thickness of 0.20mm. This stainless steel shell offers exceptional durability and corrosion resistance, protecting the internal components from environmental factors and mechanical wear. The robust construction ensures that the connector maintains its structural integrity even under frequent card insertions and removals, making it ideal for applications requiring long-term reliability.

Designed as an SD Card Slot type connector, the SD Holder Connector facilitates easy and secure insertion and removal of SD cards. The connector boasts a card push insertion and out force ranging from 0.7 to 1.20 kgf, striking a perfect balance between ensuring the card stays firmly in place during operation and allowing smooth ejection without excessive force. This feature enhances user convenience and minimizes the risk of damage to the SD card or the connector itself.

Electrical performance is a paramount consideration for the SD Card Holder Assembly, and this product excels in that regard. It supports a dielectric withstanding voltage of AC 500V R.m.s., which guarantees excellent insulation and safety during operation. This high dielectric strength minimizes the risk of electrical breakdowns, ensuring stable and uninterrupted data transmission even in demanding electrical environments.

Furthermore, the connector is rated to withstand a voltage of AC 500V, providing an additional layer of protection against voltage spikes and electrical surges. This withstanding voltage capability makes the SD Card Reader Connector suitable for a wide range of applications, including those in industrial and automotive sectors where voltage fluctuations are common.

The Secure Digital Holder Connector is designed to be compatible with standard SD cards, offering a seamless interface for reading and writing operations. Its precise engineering ensures reliable signal integrity, which is crucial for maintaining data accuracy and preventing data loss or corruption. The connector's design also supports hot-swapping, allowing users to insert or remove SD cards without powering down the host device, thus enhancing operational flexibility.

In addition to its technical specifications, the SD Card Holder Assembly is easy to integrate into various device designs thanks to its compact size and standardized form factor. Manufacturers can incorporate this connector into their products without significant design modifications, speeding up the development process and reducing production costs.

Overall, the SD Holder Connector stands out as a premium-quality component that combines mechanical robustness, electrical safety, and user-friendly features. It is an indispensable part of any device requiring secure and reliable SD card connectivity. Whether you are developing an SD card reader, a multimedia device, or an embedded system, this connector offers the performance and durability you need to ensure optimal functionality and customer satisfaction.

Features:

• Product Name: Secure Digital Holder Connector
• Connector Type: SD Card Slot
• Contact Material: Phosphor Bronze for reliable conductivity
• Plating: Tin/Lead 100u for enhanced durability and corrosion resistance
• Dielectric Withstanding Voltage: AC 500V R.m.s. ensuring high electrical insulation
• Link Material: Stainless Steel providing robust mechanical strength
• Compatible as an SD Card Reader Connector for various devices
• Designed as a Secure Digital Card Slot for secure and stable card holding

Technical Parameters:

Applications:

The LP brand Secure Digital Holder Connector, model number LP-SD027, is a high-quality SD Card Holder Assembly designed to meet the demands of modern electronic devices. Manufactured in China and certified with ISO-9001:2000, this SD Memory Slot Connector guarantees reliability and performance. With a minimum order quantity of 1000PCS and a competitive price of 0.0003 per unit, it is an ideal choice for large-scale production. The product is packaged efficiently in reel, tube, or tray formats, ensuring safe delivery within 7 to 10 days. Payment terms include T/T and L/C, supporting flexible purchasing processes, while the supply ability of 100,000PCS ensures steady availability.

This Secure Digital Holder Connector is constructed with a copper alloy base (t=0.15mm) for excellent conductivity and durability. The mounting type is surface mount, which facilitates easy integration into various circuit boards. The slider component is made from high-temperature plastic rated UL 94V-0, providing superior flame retardance and safety. These attributes make the LP-SD027 perfect for use in embedded systems and consumer electronics, where reliable data storage and transfer are critical.

The SD Card Holder Assembly is commonly applied in scenarios requiring compact and secure data storage solutions. In embedded systems, it enables seamless integration of SD cards for firmware updates, data logging, and memory expansion. Consumer electronics such as digital cameras, portable media players, and handheld gaming devices benefit greatly from the compact design and robust connection provided by this SD Memory Slot Connector. Its surface mount design ensures minimal footprint, making it suitable for slim and lightweight devices.

Additionally, the LP Secure Digital Holder Connector is ideal for use in industrial control systems, automotive infotainment, and IoT devices where secure and stable memory card connections are essential. Its high-quality construction and certification ensure long-lasting performance even in demanding environments. The versatility of the LP-SD027 model allows it to be used in a wide range of applications, making it a preferred choice for manufacturers seeking dependable SD card slot connectors.

In summary, the LP brand SD Card Holder Assembly LP-SD027 is a reliable, cost-effective, and versatile solution for securely holding SD cards in various electronic applications. Whether for embedded systems, consumer electronics, or industrial devices, this Secure Digital Holder Connector offers superior quality, fast delivery, and consistent availability, ensuring smooth production and enhanced device functionality.

Customization:

The LP brand Secure Digital Holder Connector, model number LP-SD027, is designed and manufactured in China with ISO-9001:2000 certification, ensuring high quality and reliability. This SD Card Interface Holder is made from premium copper alloy contact material, providing excellent conductivity and durability for long-term use.

With a voltage rating of AC 250V and an insulation resistance of at least 1000 MΩ, the SD Card Reader Connector guarantees safe and stable operation. It features a card push insertion/out force ranging from 0.7 to 1.20 kgf and includes a card detect switch for enhanced functionality.

We offer flexible packaging options including Reel, Tube, and Tray to suit your production needs. The minimum order quantity is 1000PCS, with a competitive price of 0.0003 per unit, supported by a supply ability of 100,000PCS. Delivery time ranges from 7 to 10 days.

Payment terms include T/T and L/C, providing convenience and security for your transactions. Choose the LP-SD027 Secure Digital Holder Connector for a reliable and efficient SD Card Interface Holder solution.

Support and Services:

Our SD Holder Connector product is designed to provide reliable and secure connections for SD card interfaces. For technical support, please refer to the product datasheet and installation guide to ensure proper handling and usage.

If you encounter any issues with the SD Holder Connector, verify that the connector is properly aligned and fully seated in the socket. Ensure that the mating SD card is compatible and free of damage or debris.

For service and maintenance, regularly inspect the connector for signs of wear or damage. Clean the contacts carefully with appropriate electronic cleaning solutions to maintain optimal connectivity.

We recommend using only authorized replacement parts to avoid compatibility issues. Firmware or hardware updates related to the SD card interface should be carried out following the manufacturer's instructions.

For further assistance, consult the technical support section on our website, where you can find FAQs, troubleshooting tips, and downloadable resources to help you resolve common issues efficiently.

Packing and Shipping:

Product Packaging: The SD Holder Connector is securely packaged in a durable, anti-static plastic bag to prevent any damage from moisture or static electricity. It is then placed inside a compact, sturdy cardboard box with cushioning materials to ensure protection during transit. Each package includes the SD Holder Connector unit along with an instruction manual and warranty information.

Shipping: We offer reliable and fast shipping options worldwide. Orders are processed within 1-2 business days. The product is shipped via trusted carriers with tracking information provided to the customer. Shipping methods include standard ground shipping, expedited shipping, and express delivery. Proper handling and packaging ensure the SD Holder Connector arrives safely and in perfect condition.
