0.8mm Pitch Female PCB Header Connector Made with Polyester UL94V0 Housing Delivering Electrical Contact and Mechanical Strength

Product Description:

The Female Header Connector is an essential component widely used in electronic assemblies to establish reliable electrical connections between printed circuit boards (PCBs) and various peripheral devices. This connector series is designed with precision and versatility in mind, ensuring excellent performance in a variety of applications. Whether you require a Female Pin Header Connector, a Female Board Header Connector, or a Female Inline Header Connector, this product line offers a comprehensive range of options to suit your specific needs.

One of the standout features of this Female Header Connector is its superior contact plating. The contacts are plated with either gold (Au) or tin (Sn) over a robust 40 microinches (n") of nickel (Ni). This plating combination ensures exceptional corrosion resistance, excellent conductivity, and long-lasting durability, which are critical for maintaining stable electrical connections over extended periods and in harsh environments. Whether used in industrial, automotive, or consumer electronics, the plating ensures minimal contact resistance and reliable signal transmission.

The connector housing is manufactured from high-quality PA6T material, enhanced with 30% glass fiber reinforcement. This material choice provides outstanding mechanical strength, thermal stability, and resistance to environmental stressors such as moisture and chemicals. PA6T+30% glass fiber ensures that the connector maintains its structural integrity even under demanding operating conditions, making it ideal for applications that require both durability and reliability.

Designed to comply with stringent industry standards, this Female Header Connector adheres to the PA6T standard, ensuring compatibility and interchangeability with a wide range of mating components. This standardization is crucial for designers and manufacturers aiming to streamline assembly processes and reduce costs while maintaining high-quality connections.

The variety of types available within this product line further enhances its adaptability. Customers can choose from vertical or right-angle configurations, surface-mount technology (SMT) options, and multiple row arrangements including single row, double row, and three rows. This versatility allows the connector to be seamlessly integrated into different PCB layouts and orientations, catering to complex design requirements and space constraints.

The contact material used in these connectors is either phosphor bronze or brass, both known for their excellent electrical and mechanical properties. Phosphor bronze offers superior elasticity and fatigue resistance, making it ideal for applications where repeated mating cycles are expected. Brass, on the other hand, provides good conductivity and strength, offering a cost-effective solution without compromising performance. These materials, combined with the high-quality plating, ensure reliable and consistent electrical contact over the product’s lifespan.

Applications for the Female Header Connector are vast and diverse, ranging from consumer electronics, telecommunications, and computing devices to automotive systems and industrial control equipment. Its ability to serve as a Female Pin Header Connector makes it perfect for connecting pins on PCBs, while its role as a Female Board Header Connector facilitates board-to-board connections. Additionally, the Female Inline Header Connector variant is ideal for inline cable connections, providing flexibility in wiring harnesses and modular assemblies.

In conclusion, the Female Header Connector stands out as a robust, versatile, and high-performance solution for various electronic connection needs. Its gold or tin plating over nickel, high-strength PA6T+30% glass fiber housing, compliance with PA6T standards, multiple configuration options, and premium contact materials like phosphor bronze and brass all contribute to its reliability and durability. Whether you are designing a compact electronic device or a complex industrial system, this connector series offers the quality and flexibility required to ensure seamless and long-lasting electrical connections.

Features:

• Product Name: Female Electrical Header Connector
• Type: Female Pin Header Connector / Female Socket Header Connector
• Withstanding Voltage: AC 500V
• Insulation Resistance: 1000MΩ Min
• Material Standard: PA6T
• Insulator Material: LCP / NYLON / PA6T (UL94V-0)
• Server Compatibility: Openresty

Technical Parameters:

Applications:

The LP Female Header Connector, model number LP-FH027, is a highly reliable and versatile component designed for a wide range of electronic applications. Manufactured in China and certified under ISO-9001:2000, this connector is engineered to meet stringent quality standards, ensuring consistent performance and durability. With a minimum order quantity of 1000PCS and a competitive price of 0.0001 per unit, it offers excellent value for manufacturers and designers seeking high-quality female header solutions.

This Female Header Pin Connector is ideal for use in industries requiring robust and stable electrical connections, such as consumer electronics, automotive systems, telecommunications, and industrial equipment. Its ability to operate within a temperature range of -40° to +105° makes it suitable for both indoor and harsh outdoor environments. The connector’s contact plating options, including gold (Au) or tin (SN) over 40n" nickel, guarantee low contact resistance of 30mΩ max, ensuring efficient signal transmission and minimal power loss.

Thanks to its innovative design with mounting types available in both Through Hole and Surface Mount Technology (SMT), the LP-FH027 Female Inline Header Connector can be easily integrated into various PCB layouts. The insulator materials, which include LCP, Nylon, and PA6T (UL94V-0), provide excellent electrical insulation and flame retardancy, enhancing safety and longevity in electronic assemblies.

The packaging options of Reel, Tube, Tray, and Polybag provide flexibility for different production and assembly processes, while the fast delivery time of 7 to 10 days supports efficient manufacturing cycles. Payment terms such as T/T, Western Union, and L/C further facilitate smooth procurement and international trade.

Specifically designed as a Female Socket Header Connector, this product is widely used in connectors for motherboards, embedded systems, communication devices, and custom electronic modules where reliable female pin connections are essential. With a supply ability of 100,000PCS, LP ensures that production demands can be met promptly, making the LP-FH027 an excellent choice for engineers and manufacturers looking to implement dependable female header connectors in their projects.

Customization:

Introducing the LP Female Wire Header Connector, model number LP-FH027, proudly manufactured in China. This Female Header Socket Connector is certified with ISO-9001:2000, ensuring high quality and reliability for your applications.

Our Female Wire Header Connector offers flexibility with a pitch range of 0.8mm, 1.0mm, 1.27mm, 2.0mm, and 2.54mm, accommodating various design requirements. The insulator is made from durable materials such as LCP, Nylon, and PA6T (UL94V-0), providing excellent electrical insulation and thermal resistance.

The plastics height options include 2.0mm, 3.12mm, 4.3mm, 4.5mm, 5.0mm, 5.9mm, 6.35mm, 7.1mm, and 8.5mm, crafted from PA6T with 30% glass fiber for enhanced strength and stability. This ensures the connector can operate effectively in temperatures ranging from -40 ℃ to +105 ℃.

With a supply ability of 100,000 PCS and a minimum order quantity of 1,000 PCS, the LP Female Wire Header Connector is ideal for mass production needs. Pricing starts at 0.0001 per unit, making it a cost-effective solution without compromising quality.

Packaging options include Reel, Tube, Tray, and Polybag, tailored to your logistics and handling preferences. Delivery is prompt within 7 to 10 days, supported by flexible payment terms including T/T, Western Union, and L/C.

Choose the LP Female Header Socket Connector for your next project to benefit from superior materials, versatile specifications, and reliable supply chain management.
