Current Rating 1.0Amp Insulation Displacement Connector Socket Electrical Connection for Wire Harness and Circuit Assembly

Product Description:

The IDC Cable Socket Connector is an essential component widely used in electronic assemblies and wire-to-board connections. Designed to provide reliable and efficient connectivity, this IDC Connector Socket Header offers a versatile and robust solution for various industrial and consumer applications. With its ability to accommodate a broad operating temperature range from -65°C to +125°C, this connector is ideal for environments requiring high thermal endurance and stability. Whether deployed in harsh industrial settings or standard commercial electronics, the IDC Socket Header Connector guarantees consistent performance and durability.

One of the key features of this IDC Cable Socket Connector is its compliance with stringent industry standards, including RoHS and UL Recognition. These certifications ensure that the product meets environmental safety regulations and maintains high-quality manufacturing processes, which are critical for minimizing hazardous substances and ensuring user safety. The RoHS compliance denotes that the connector is free from harmful materials such as lead, mercury, and cadmium, making it environmentally friendly. Meanwhile, the UL Recognized status confirms that the connector has undergone rigorous testing for electrical safety and reliability, which is vital for both manufacturers and end-users seeking dependable connectivity solutions.

The IDC Connector Socket Header is available in multiple configurations to suit a wide range of design requirements. Customers can choose from vertical, right angle, SMT (Surface Mount Technology), and double row types, offering flexibility in PCB layout and assembly. The vertical and right angle options allow for different orientations on the printed circuit board, facilitating efficient use of space and optimal signal routing. SMT versions are designed for surface mounting, enabling automated assembly processes and enhanced production efficiency, while through-hole mounting types provide strong mechanical connections for applications subjected to mechanical stress or vibrations.

Another important electrical characteristic of the IDC Socket Header Connector is its dielectric withstanding voltage of AC 500V. This rating ensures that the connector can withstand high voltage stress without electrical breakdown or insulation failure. Such a feature is crucial in safeguarding the integrity of electronic circuits, especially in applications involving power distribution or signal transmission where voltage spikes may occur. The robust dielectric insulation contributes to the overall safety and reliability of the electronic system, preventing short circuits and enhancing the lifespan of connected components.

Mounting versatility is a hallmark of the IDC Cable Socket Connector. Depending on the specific application needs, users can select either through-hole or surface mount options. Through-hole mounting involves inserting the connector pins through drilled holes on the PCB, followed by soldering, which provides a secure mechanical bond ideal for high-reliability applications. Surface mount connectors, on the other hand, are soldered directly onto the PCB surface, offering advantages such as reduced assembly time, lower profile designs, and compatibility with modern automated manufacturing techniques. This broad mounting compatibility allows designers to integrate the IDC Socket Header Connector seamlessly into various electronic systems.

Overall, the IDC Connector Socket Header stands out as a high-performance, reliable, and environmentally compliant interconnection solution. Its wide operating temperature range, adherence to RoHS and UL standards, multiple type configurations, high dielectric withstanding voltage, and flexible mounting options make it a preferred choice for engineers and manufacturers. Whether used in communication devices, automotive electronics, industrial machinery, or consumer gadgets, this IDC Cable Socket Connector ensures stable connections, efficient signal transmission, and long-term durability, meeting the demanding requirements of modern electronic applications.

Features:

• Product Name: IDC Socket / BOX Header
• Type: Vertical, Right Angle, SMT, Double Row options available
• Current Rating: 3A Per Contact
• Contact Resistance: 20M Ohms Max
• Compliance Standards: RoHS, UL Recognized
• Features Insulation Displacement Connector Socket technology for reliable connections
• Also known as IDC Connector Socket Header, ideal for various cable assembly applications
• Compatible with IDC Cable Socket Connector systems for efficient wiring solutions

Technical Parameters:

Applications:

The LP-BX028 IDC Socket / BOX Header, manufactured by the reputable brand LP in China, is an exceptional component designed to meet diverse application needs in the electronics industry. This high-quality product is certified under ISO-9001:2000, ensuring superior manufacturing standards and reliability. It is widely used in various occasions and scenarios where robust and efficient electrical connections are paramount.

One of the primary application occasions for the LP-BX028 is in telecommunications equipment, where the Insulation Displacement Contact Socket plays a crucial role in connecting IDC cables without the need for stripping insulation. This feature significantly speeds up assembly and maintenance processes in telecom systems, making it ideal for large-scale installations and network infrastructure projects.

In addition, the IDC Socket Header Connector is extensively used in computer hardware assemblies and consumer electronics. Its design supports both Through Hole and Surface Mount mounting types, providing flexibility for different PCB layouts and design requirements. The high-temperature thermoplastic insulator material ensures durability and stability even under demanding thermal conditions, making it suitable for use in industrial control systems and automotive electronics.

The IDC Cable Socket Connector also finds applications in home appliances and medical devices where precise and reliable electrical connections are critical. The contact material made of phosphor bronze enhances conductivity and resistance to corrosion, ensuring long-term performance. Furthermore, the product complies with RoHS and UL Recognized standards, making it a safe and environmentally friendly choice for manufacturers and end-users alike.

Packaging options such as Reel, Tube, Tray, and Polybag provide convenience for various production scales, while a minimum order quantity of 1000PCS and a competitive price of 0.0001 per unit make it an economical solution for mass production. With a supply ability of 100,000PCS and a delivery time of 7 to 10 days, the LP-BX028 IDC Socket / BOX Header is well-suited for manufacturers requiring reliable and timely component sourcing.

Payment terms including T/T, Western Union, and L/C offer flexible financial options for global customers. The product’s insulation resistance of 1000M Ohms minimum ensures excellent electrical isolation, enhancing the safety and performance of connected systems. Overall, the LP-BX028 IDC Socket / BOX Header is an indispensable component for various electronic applications demanding high reliability, ease of installation, and compliance with international standards.

Customization:

Introducing the LP brand IDC Socket / BOX Header product, model number LP-BX028, manufactured in China with ISO-9001:2000 certification. This Box Header IDC Connector is designed to meet high standards of quality and reliability.

The IDC Socket Header Connector features a black PA6T UL 94V-0 insulator, ensuring durability and excellent dielectric withstanding capabilities up to AC 500V. It supports a current rating of 1.0 Amp and utilizes an Insulation Displacement Contact (IDC) termination method for efficient and secure connections.

Available in packaging options including Reel, Tube, Tray, and Polybag, the IDC Socket Connector Assembly is ready for various application needs. With a minimum order quantity of 1000PCS and a competitive price of 0.0001 per unit, LP offers a supply ability of 100,000PCS with a delivery time of 7 to 10 days.

Payment terms are flexible, accepting T/T, Western Union, and L/C, ensuring a smooth transaction process for customers worldwide. Choose LP's Box Header IDC Connector for dependable performance and customization services tailored to your requirements.
