Operating Temp Minus 40 Celsius To Plus 105 Celsius FPC Ribbon Cable Connector Made From Loeker Material PPS UL94V-0 RoHS Compliant For Industrial

Product Description:

The FPC / FFC Connector is a high-quality electronic component designed specifically for connecting Flexible Printed Circuits (FPC) and Flat Printed Cables (FFC) with exceptional reliability and performance. These connectors play a crucial role in modern electronic devices by ensuring secure and stable connections between flexible circuits and printed circuit boards, enabling compact and efficient device designs. Manufactured with precision and adhering to stringent industry standards, this connector is ideal for applications requiring durability, flexibility, and high electrical performance.

One of the key features of this FPC / FFC Connector is its use of premium materials to enhance durability and safety. The lock lever material is made from PPS (Polyphenylene Sulfide), which meets the UL94V-0 flammability rating. This means the connector exhibits excellent flame retardant properties, ensuring compliance with safety regulations and reducing fire hazards in electronic assemblies. Additionally, the product is RoHS compliant, ensuring it is environmentally friendly and free from hazardous substances, making it suitable for use in eco-conscious manufacturing environments.

Operating within a wide temperature range from -40°C to +105°C, this connector is built to perform reliably in various environmental conditions. Whether it is used in consumer electronics, automotive applications, or industrial equipment, the connector maintains stable electrical contact and mechanical integrity under thermal stress, making it a dependable choice for demanding applications.

The contact material used in this Flexible Printed Circuit Connector is a copper alloy combined with phosphor bronze. Copper alloy offers excellent electrical conductivity, which is critical for maintaining signal integrity and reducing power losses. Phosphor bronze contributes to the connector’s mechanical strength and corrosion resistance, ensuring long-lasting performance even after repeated mating and unmating cycles. This combination results in a connector that not only delivers superior electrical performance but also withstands mechanical wear and environmental factors effectively.

This product offers two main connector types: ZIF (Zero Insertion Force) and LIF (Low Insertion Force). Both types are designed to facilitate easy and secure connections with flexible circuits. The ZIF connector allows for effortless cable insertion without applying force, minimizing the risk of damage to delicate flexible printed circuits during assembly. On the other hand, the LIF connector provides a balance between insertion force and retention strength, suitable for applications where a more secure connection is necessary without the complexity of locking mechanisms. This versatility enables designers to choose the most appropriate connector type based on their specific application requirements.

Furthermore, the solder tab of the connector is crafted from phosphor bronze, enhancing the mechanical durability and solderability of the component. This ensures a strong and reliable solder joint on the printed circuit board, which is essential for maintaining consistent electrical connections throughout the product’s lifecycle. The phosphor bronze solder tab also contributes to resistance against corrosion and fatigue, supporting long-term operational stability.

In summary, this Flexible Printed Circuit Connector and Flat Printed Cable Connector is an exceptional solution for interconnecting flexible circuits in a wide range of electronic devices. With materials such as PPS for the lock lever, copper alloy and phosphor bronze for contacts, and a robust phosphor bronze solder tab, the connector guarantees safety, durability, and excellent electrical performance. Its ability to operate efficiently within a temperature range of -40°C to +105°C, combined with the availability of ZIF and LIF connector types, makes it highly adaptable to various industrial, consumer, and automotive applications. Choosing this Flat Printed Cable Connector ensures a reliable, high-quality connection that meets modern electronic design demands, enhancing overall device functionality and longevity.

Features:

• Product Name: FPC / FFC Connector
• Flexible Flat Cable Interface
• FPC Ribbon Cable Connector
• FFC Flexible Circuit Connector
• Solder Tab Material: Phosphor Bronze
• Mounting Type: Surface Mount Technology (SMT) and Through Hole Technology (THT)
• Contact Resistance: 20mΩ max.
• Available Pitch Sizes: 0.5mm, 1.0mm, 1.25mm, 1.27mm
• Free Sample Available

Technical Parameters:

Applications:

The Loupeng LP-FPC042 is a high-quality FPC Ribbon Cable Connector designed to meet the demanding requirements of modern electronic applications. As a Flexible Printed Circuit Connector, it offers exceptional reliability and performance, making it ideal for various product application occasions and scenarios. Manufactured in China and certified with ISO-9001:2000, this connector guarantees top-notch quality and consistency, ensuring optimal electrical connectivity for your projects.

One of the most common application occasions for the Loupeng LP-FPC042 Flat Flexible Cable Connector is in consumer electronics. Devices such as smartphones, tablets, laptops, and wearable gadgets frequently require compact and reliable connectors to link flexible printed circuits to the main board. The LP-FPC042’s ZIF (Zero Insertion Force) and LIF (Low Insertion Force) connector types facilitate easy installation and secure connections, making it a preferred choice for assembly lines where efficiency and durability are critical.

In addition to consumer electronics, this Flexible Printed Circuit Connector is widely used in automotive applications. Modern vehicles incorporate numerous electronic control units and sensors that depend on flexible cables for space-saving and vibration-resistant connections. The LP-FPC042’s high insulator resistance of 500 Megohms minimum and dielectric withstanding capability of AC 500V ensure stable performance even in harsh automotive environments.

The industrial sector also benefits from the Loupeng LP-FPC042. Industrial automation equipment, medical devices, and instrumentation often require reliable flat flexible cable connectors capable of withstanding rigorous operational conditions. The connector’s contact material, composed of copper alloy and phosphor bronze, combined with a PPS UL94V-0 RoHS-compliant loeker material, offers excellent electrical conductivity and flame resistance, meeting stringent safety and environmental standards.

With a minimum order quantity of 1000PCS and a competitive price of 0.03 per unit, the LP-FPC042 is suitable for mass production projects. Packaging options such as reels and tubes facilitate efficient handling and integration into automated manufacturing processes. Furthermore, the delivery time of 8 to 12 days and flexible payment terms including T/T and L/C make it convenient for global customers to procure this Flat Flexible Cable Connector.

Overall, the Loupeng LP-FPC042 FPC Ribbon Cable Connector is an indispensable component in a variety of application scenarios, from consumer electronics and automotive systems to industrial machinery and medical equipment. Its combination of robust materials, reliable performance, and streamlined logistics support ensures it meets the diverse needs of modern electronic manufacturing.

Customization:

Introducing the Loupeng LP-FPC042 FPC / FFC Connector, a high-quality FFC Flexible Flat Cable Connector designed to meet your precise customization needs. Originating from China and certified under ISO-9001:2000, this connector guarantees reliable performance and quality assurance for your projects.

Our FFC Cable Assembly Connector features an insulator resistance of 500 Megohms minimum and supports a current rating of 0.5 Amps, ensuring stable and efficient electrical connectivity. Available in multiple pitch options including 0.5mm, 1.0mm, 1.25mm, and 1.27mm, it offers versatile compatibility with various flexible flat cable interfaces.

We provide flexible packaging options such as reel or tubes to suit different production requirements. With a supply ability of 100,000 PCS and a minimum order quantity of 1000 PCS, we cater to both small and large scale orders. The price is competitively set at $0.03 per piece.

Our delivery time ranges from 8 to 12 days, ensuring timely fulfillment of your orders. Payment terms include T/T and L/C for your convenience. Additionally, we offer free samples so you can evaluate the product before making a purchase.

The LP-FPC042 connector can withstand a maximum processing temperature of 230°C for 30 to 60 seconds, and up to 260°C for 10 seconds, providing excellent thermal endurance for soldering processes.

Choose Loupeng’s FPC / FFC Connector for your next project to benefit from a dependable and customizable flexible flat cable interface solution that meets international quality standards.
