Plug Type Push Pull Coupling Connector Featuring Male Pin Contact Ensuring Signal Transmission in Communication Equipment

Product Description:

The Push Pull Connector is an advanced and versatile solution designed to meet the demanding requirements of modern electronic and electrical applications. Known for its robust construction and reliable performance, this connector is ideal for environments where durability and secure connections are critical. The product is available in both plug and socket types, making it suitable for a wide range of configurations and applications.

One of the standout features of this Push Pull Connector is its exceptional environmental resistance. It has been rigorously tested under the environmental conditions of 20 / 80 / 21, ensuring excellent performance in varying temperature and humidity levels. This makes it particularly suitable for use in harsh environments where other connectors might fail. The Push Pull Waterproof Connector variant further enhances this capability by offering superior sealing against water ingress, making it an excellent choice for outdoor and industrial applications that require reliable waterproof performance.

Shielding is another critical aspect of this Push Pull Circular Connector. It provides outstanding electromagnetic interference (EMI) shielding, with a shielding effect greater than 80 dB at 1 GHz and exceeding 95 dB at 10 MHz. This high level of shielding ensures that signals remain clean and free from external noise and interference, which is essential for maintaining signal integrity in sensitive electronic systems. Whether used in communication devices, medical equipment, or industrial machinery, this connector helps to preserve the quality and reliability of data transmission.

The connector is available in two orientation styles: straight and right angle. This flexibility allows for easy integration into various design layouts, providing engineers and designers with the freedom to choose the most space-efficient and practical solution for their specific application. Whether the connection needs to be aligned straight or bent at a right angle, the connector maintains its mechanical stability and electrical performance.

Constructed with PPS (Polyphenylene Sulfide) insulation material, the Push Pull Quick Release Connector boasts excellent thermal and chemical resistance. PPS is well-known for its high mechanical strength, dimensional stability, and resistance to heat and chemicals, which ensures that the connector performs reliably even under extreme operating conditions. The use of PPS insulation contributes to the overall durability and longevity of the connector, making it a cost-effective choice for long-term installations.

The push-pull mechanism is a key feature that sets this connector apart from traditional connectors. It allows for quick and secure mating and unmating without the need for tools, significantly reducing the time required for installation and maintenance. This quick release functionality is particularly advantageous in applications where connectors need to be frequently connected and disconnected, such as in modular systems, test equipment, or portable devices. The push-pull design also ensures a firm and vibration-resistant connection, preventing accidental disconnections in dynamic environments.

In summary, the Push Pull Connector offers a comprehensive combination of durability, environmental resistance, EMI shielding, and ease of use. Its availability in plug and socket types, straight and right-angle orientations, and the use of PPS insulation material make it a versatile choice for a wide range of industries. Whether you require a Push Pull Circular Connector for high-performance electronics, a Push Pull Waterproof Connector for outdoor applications, or a Push Pull Quick Release Connector for rapid and secure connections, this product is engineered to deliver dependable and high-quality performance every time.

Features:

• Product Name: Push-Pull Connector
• Available Orientations: Straight and Right Angle
• Insulation Material: High-quality PPS for durability and heat resistance
• Excellent Shielding Effect: Greater than 80 dB at 1 GHz and greater than 95 dB at 10 MHz
• Durable Shell Material: Made from robust Copper Alloy
• Low Leakage Rate (He): Less than 10⁻⁷ mbar·L·s⁻¹ ensuring superior airtightness
• Features Push Pull Cable Connector design for secure and reliable connections
• Incorporates Push Pull Quick Release Connector mechanism for easy and fast coupling and decoupling
• Ideal Push Pull Connector solution for various industrial and electronic applications

Technical Parameters:

Applications:

The LP-PU001 Push Pull Connector, manufactured by LP in China, is an advanced Push Pull Coupling Connector designed to meet rigorous industrial and commercial application demands. Certified with ISO-9001:2000, this connector guarantees high-quality performance and reliability. With a minimum order quantity of 1000PCS and a competitive price of 0.08 per unit, it is an excellent choice for large-scale projects requiring efficient and cost-effective connectivity solutions.

This Push Pull Circular Connector is widely used in various application occasions and scenarios where secure, quick, and reliable connections are essential. Thanks to its impact resistance capability of 100g 6ms, it performs exceptionally well in environments subject to vibrations and shocks, making it ideal for use in industrial automation, medical equipment, military communication devices, and aerospace systems. Its robust construction and solvent corrosion resistance—average for PSU, good for PPSU, and very good for PEEK materials—ensure durability even in challenging chemical exposure conditions.

The LP-PU001 Push Pull Metal Connector offers versatile orientation options, including straight and right angle configurations, which provide flexibility in panel mount installations. This feature is particularly beneficial in compact electronic devices, instrumentation panels, and control cabinets where space optimization is critical. The availability of both male pin and female pin contact types further enhances its adaptability across diverse electrical and electronic systems.

Packaging details such as tube or tray options facilitate convenient handling and storage, while the supply ability of up to 100,000PCS ensures timely fulfillment of bulk orders. The delivery time of 7 to 10 days, combined with flexible payment terms including T/T, Western Union, and L/C, makes the LP-PU001 an accessible and reliable connector solution for manufacturers and system integrators worldwide.

In summary, the LP Push Pull Coupling Connector LP-PU001 is perfectly suited for use in harsh industrial environments, medical instrumentation, telecommunications, aerospace, and military applications. Its secure push-pull locking mechanism guarantees fast and safe connections and disconnections, significantly improving operational efficiency and reducing maintenance downtime. Whether you require a Push Pull Circular Connector or a Push Pull Metal Connector, the LP-PU001 offers exceptional performance, durability, and versatility to meet diverse application demands.

Customization:

Our Push Pull Connector, model LP-PU001 from the trusted brand LP, is designed and manufactured in China with ISO-9001:2000 certification, ensuring top quality and reliability. This Push Pull Circular Connector offers excellent shielding effect with > 80 DB at 1GHz and > 95 DB at 10MHz, providing superior signal protection for your applications.

With an impact resistance of 100g 6ms and anti-vibration performance ranging from 10-2000Hz at 15g, this Push Pull Circular Connector is built to withstand harsh environments and demanding conditions. The connector type is available in both plug and socket options, catering to versatile connectivity needs.

We offer customization services with a minimum order quantity of 1000PCS, priced competitively at $0.08 per unit. Packaging is available in tube or tray formats to suit your storage and handling preferences. Our supply ability is strong, capable of delivering up to 100,000PCS with a delivery time of 7 to 10 days.

Payment terms are flexible, including T/T, Western Union, and L/C, making the procurement process convenient for our global customers. Choose our Push Pull Connector customization services for a reliable, high-performance Push Pull Circular Connector tailored to your specific requirements.

Support and Services:

For technical support and services related to the Push-Pull Connector product, please refer to the comprehensive user manual provided with your purchase. Our support team is dedicated to assisting you with installation guidance, troubleshooting, and maintenance tips to ensure optimal performance of your connector.

Should you encounter any issues, we recommend checking the FAQ section on our website, which covers common problems and their solutions. Additionally, detailed technical specifications and wiring diagrams are available to help you integrate the Push-Pull Connector seamlessly into your application.

We also offer repair and replacement services for connectors that are under warranty or have been damaged due to manufacturing defects. For customized support, including advice on connector compatibility and system design, our technical experts are available to provide tailored solutions.

To maximize the lifespan and reliability of your Push-Pull Connector, regular inspection and cleaning are advised. Use only recommended cleaning agents and follow the maintenance procedures outlined in the product documentation.

Your satisfaction and the performance of your Push-Pull Connector are our top priorities. Please utilize the available resources and services to ensure your connector operates effectively in all conditions.

Packing and Shipping:

Our Push-Pull Connector is carefully packaged to ensure maximum protection during transit. Each connector is individually wrapped in anti-static material and placed in a sturdy, cushioned box to prevent damage from impacts or vibrations.

The packaging is designed to be compact yet secure, minimizing the environmental footprint while maintaining product integrity. Clear labeling and handling instructions are included to facilitate safe and efficient shipping and handling.

We ship our Push-Pull Connectors using reliable carriers with tracking options to ensure timely delivery. For bulk orders, connectors are packed in larger, reinforced cartons with additional padding to safeguard multiple units.

Customers can expect their Push-Pull Connector products to arrive in excellent condition, ready for immediate use in their applications.
