1.0AMP Current Rating Single Row Pin Connector with 1000M Ohms Min Insulation Resistance Electrical Connection Solution

Product Description:

The Straight Pin Header Connector is a versatile and essential component widely used in electronic assemblies for establishing reliable electrical connections between printed circuit boards (PCBs) and other electronic components. Designed with precision and durability in mind, this Pin Header Connector offers a range of configurations to suit various application requirements, making it a preferred choice for engineers and manufacturers alike.

One of the key features of this connector is its variety in plastics height, which includes options of 1.0mm, 1.5mm, 2.0mm, 2.5mm, and 2.54mm. This range allows designers to select the appropriate connector height that best fits the spatial and mechanical constraints of their projects. The plastics used in the housing are engineered to provide excellent insulation and mechanical stability, ensuring the connector maintains integrity even under demanding conditions.

The contact pins of the Straight Pin Header Connector are made from high-quality copper alloys. Copper alloys are chosen for their excellent electrical conductivity and corrosion resistance, which are critical for maintaining consistent signal transmission and minimizing power loss. The contacts are also designed to provide a secure and stable connection with mating components, reducing the risk of intermittent faults and ensuring long-term reliability.

Durability is another significant attribute of this Pin Header Connector. It is rated for 100 mating cycles, which means it can withstand repeated connections and disconnections without degradation in performance. This durability makes it suitable for applications where connectors may need to be frequently reconfigured or serviced, such as in prototyping, testing, or modular systems.

The Pin Header Connector is available with a number of pins ranging from 2 to 40 pins. This wide range of pin counts enables users to select connectors that match the exact number of electrical connections required in their designs. Whether a simple two-pin connection or a complex interface requiring up to forty pins, this product line offers flexible options to accommodate diverse electronic interfacing needs.

In addition to its straight pin configuration, the connector is also available as a Surface Mount Pin Header, which is specifically designed for surface mount technology (SMT) assembly processes. The surface mount version allows for automated placement and soldering directly onto the PCB surface, enhancing manufacturing efficiency and reducing assembly time. This makes the Surface Mount Pin Header ideal for modern electronics manufacturing where high-speed production and miniaturization are critical.

The Straight Pin Header Connector is widely used across various industries including consumer electronics, automotive, telecommunications, industrial controls, and computer hardware. Its reliable electrical performance, robust mechanical design, and flexible configurations make it an indispensable component in countless electronic systems.

In summary, the Straight Pin Header Connector offers a combination of customizable plastics height options, high-quality copper alloy contacts, solid durability with 100 mating cycles, and a broad range of pin numbers from 2 to 40 pins. Its availability in both traditional through-hole and Surface Mount Pin Header styles further enhances its versatility, making it a dependable solution for any electronic design requiring reliable interconnections. Whether for prototyping, production, or repair, this Pin Header Connector ensures consistent performance and ease of use, solidifying its role as a fundamental element in modern electronic assemblies.

Features:

• Product Name: PIN Header Connector
• Contact Material: Copper Alloys for excellent conductivity
• Available Plastics Height: 1.0mm, 1.5mm, 2.0mm, 2.5mm, and 2.54mm
• Retention Force: Minimum 700g to ensure secure connections
• Current Rating Options: 1.0AMP or 3.0AMP
• Pitch Sizes: 0.8mm, 1.0mm, 1.27mm, 2.0mm, and 2.54mm
• Suitable for Right Angle Pin Header configurations
• Compatible with PCB Mount Pin Header applications
• Available in Surface Mount Pin Header style for versatile mounting

Technical Parameters:

Applications:

The LP brand's PIN Header Connector, model number LP-P054, is a versatile and reliable component designed for various electronic applications. Manufactured in China and certified under ISO-9001:2000 standards, this connector guarantees high quality and performance. Its exceptional supply ability of 100,000 PCS ensures that large-scale production requirements are met efficiently, with a minimum order quantity of 1000PCS. Priced competitively at 0.0001 per unit, the LP-P054 is an economical choice for manufacturers and developers alike.

This product is widely used in numerous application occasions and scenarios, particularly where robust and stable electrical connections are critical. The Through Hole Pin Header design offers excellent mechanical stability, making it suitable for PCB mounting in industrial automation equipment, consumer electronics, communication devices, and automotive electronics. The availability of both Male Pin Header Connectors and Female Pin Header Connectors allows for flexible and secure mating interfaces, facilitating seamless connections in complex circuit designs.

The LP-P054 PIN Header Connector features pins crafted from high-quality phosphor bronze or brass, ensuring excellent electrical conductivity and durability. The insulator materials used include LCP, Nylon, PA6T, and PBT+30% Glass Fiber, all compliant with UL94V-0 flame retardant standards, providing excellent thermal stability and mechanical strength. This makes the connector ideal for use in environments with fluctuating temperatures and demanding mechanical stresses.

The plating options of gold, tin, and nickel enhance corrosion resistance and optimize signal transmission, which is essential for high-frequency and sensitive electronic applications. With plastic heights ranging from 1.0mm to 2.54mm, customers can select the appropriate size to fit their specific design requirements.

Packaging options such as reel, tube, tray, and polybag provide convenience in handling and storage, supporting automated assembly lines and reducing production downtime. The delivery time of 7 to 10 days combined with flexible payment terms, including T/T, Western Union, and L/C, further facilitate smooth procurement processes.

Overall, the LP-P054 PIN Header Connector is an ideal solution for manufacturers looking for reliable Through Hole Pin Header, Male Pin Header Connector, and Female Pin Header Connector options that meet high standards of quality, efficiency, and cost-effectiveness across various electronic application scenarios.

Customization:

LP brand offers high-quality PIN Header Connector, model number LP-P054, manufactured in China with ISO-9001:2000 certification. Our product customization services cater to various specifications including Single Row Pin Connector, Right Angle Pin Header, and other Pin Header Connector types such as Vertical, SMT, Double Row, and Three Rows configurations.

We ensure superior insulation resistance of 5000 megaohms minimum and a fire protection grade of UL94V-0 for safety and reliability. The pin material options include durable Phosphor Bronze and Brass, suitable for operation temperatures ranging from -65°C to +125°C.

Our supply ability is 100,000PCS with a minimum order quantity of 1000PCS. Pricing starts at 0.0001 per unit, with flexible packaging options including Reel, Tube, Tray, and Polybag to meet your specific needs.

Delivery time is typically 7 to 10 days, and we accept multiple payment terms such as T/T, Western Union, and L/C to facilitate smooth transactions. Choose LP's PIN Header Connector customization services for reliable and versatile connector solutions tailored to your requirements.
