Retention Force 700g Min Surface Mount Pin Header Featuring Durability 100 Cycles Suitable for Precision PCB Applications

Product Description:

The PIN Header Connector is an essential component widely used in electronic assemblies for establishing reliable electrical connections between printed circuit boards (PCBs) and various electronic devices. Designed with precision and engineered for durability, this connector offers excellent performance in diverse applications, ranging from consumer electronics to industrial equipment. The PIN Header Connector is available in multiple configurations, including vertical, right angle, SMT (Surface Mount Technology), single row, double row, and three-row types, providing versatile mounting options to suit different design requirements.

One of the standout features of this PIN Header Connector is its impressive retention force, rated at a minimum of 700 grams. This high retention force ensures a secure and stable connection, preventing accidental disconnections even under mechanical stress or vibration. This attribute is particularly important in applications where reliability and longevity are critical, such as in automotive electronics, telecommunications, and aerospace systems.

In terms of electrical performance, the PIN Header Connector excels with a low contact resistance of no more than 20 milliohms. This low resistance minimizes energy loss and heat generation at the contact points, enhancing the overall efficiency and reliability of the electrical circuit. The contacts are made from high-quality copper alloys, chosen for their excellent conductivity and resistance to corrosion. This material choice ensures consistent signal transmission and long-lasting durability, even in harsh environmental conditions.

The connector is designed to withstand a dielectric voltage of AC 500V, which means it can operate safely and reliably under high voltage conditions without risk of electrical breakdown or insulation failure. This dielectric withstanding capability is crucial for applications requiring robust insulation and protection against electrical interference, ensuring the safety and integrity of the electronic system.

When it comes to mounting options, the PIN Header Connector offers flexibility with PCB mount pin header, through hole pin header, and right angle pin header variations. The PCB mount pin header is designed for easy soldering directly onto the surface of printed circuit boards, making it ideal for compact and densely packed electronic assemblies. The through hole pin header provides a strong mechanical bond by inserting pins through holes in the PCB and soldering them on the opposite side, which enhances mechanical stability and electrical performance. The right angle pin header is specially designed to allow connections at a 90-degree angle to the PCB, enabling more efficient use of space and facilitating connections in complex layouts or confined spaces.

Additionally, the availability of single row, double row, and three-row configurations allows designers to choose the optimal pin density and connector size for their specific application. Single row headers are suitable for simple, low-pin-count connections, while double and three-row headers provide higher pin counts in a compact footprint, supporting more complex circuit designs.

Overall, the PIN Header Connector combines robust mechanical strength, superior electrical performance, and versatile mounting options to meet the demanding requirements of modern electronic systems. Whether you need a vertical connector for straightforward PCB interfacing, a right angle pin header for space-saving layouts, or an SMT version for automated assembly processes, this connector series provides reliable solutions that ensure stable and efficient electrical connections. Its copper alloy contacts, high retention force, low contact resistance, and excellent dielectric withstanding capability make it a dependable choice for a wide range of industrial, commercial, and consumer electronics applications.

Features:

• Product Name: PIN Header Connector
• Number of Pins: 2 To 40 Pins
• Operation Temperature: -65°C To +125°C
• Processing Temperature: 260℃ For 10 Seconds
• Contact Resistance: 20M Ohms Max
• Gender: Male
• Type: Male Pin Header Connector
• Mounting Style: PCB Mount Pin Header
• Configuration: Straight Pin Header Connector

Technical Parameters:

Applications:

The LP brand PIN Header Connector, model number LP-P050, is a highly reliable PCB Mount Pin Header designed to meet diverse electronic assembly needs. Manufactured in China and certified under ISO-9001:2000 standards, this connector guarantees superior quality and consistency. With a minimum order quantity of 1000PCS and a competitive price of 0.0001 per unit, it is an ideal choice for both small-scale and large-scale production runs. The product is available in various packaging options including Reel, Tube, Tray, and Polybag, facilitating flexible logistics and handling. Delivery is prompt within 7 to 10 days, supported by multiple payment terms such as T/T, Western Union, and L/C, ensuring convenience for global customers.

The LP-P050 PCB Mount Pin Header excels in applications requiring robust electrical connections on printed circuit boards. Its contact resistance is maintained at a maximum of 20 milliohms, ensuring minimal signal loss and high conductivity. The connector operates efficiently across a wide temperature range from -65°C to +125°C, making it suitable for use in harsh environments and temperature-sensitive applications. The contacts are made of high-quality copper alloys, which provide excellent electrical performance and mechanical durability. Additionally, the insulation resistance exceeds 1000M ohms minimum, offering reliable isolation between pins and preventing electrical shorts.

This Single Row Pin Connector is widely used in various electronic devices and equipment, including consumer electronics, industrial machinery, automotive electronics, and communication devices. Its gold, tin, or nickel plating options enhance corrosion resistance and ensure long-lasting performance, especially in environments prone to oxidation or wear. The LP-P050 PCB Mount Pin Header is particularly favored for its easy installation on PCBs, making it a go-to component in prototyping, manufacturing, and repair scenarios. Engineers and designers appreciate this connector for its precision, reliability, and cost-effectiveness.

In summary, the LP-P050 PCB Mount Pin Header by LP brand is a versatile, high-quality Single Row Pin Connector suitable for a broad range of application occasions and scenarios. Whether used in industrial automation systems, consumer gadgets, or communication infrastructure, it delivers dependable performance. Its excellent electrical characteristics, robust plating, and flexible packaging options make it an indispensable component in modern electronic assembly and manufacturing processes.

Customization:

Our LP brand PIN Header Connector, model number LP-P050, is proudly made in China and certified under ISO-9001:2000 standards, ensuring top quality and reliability for your electronic assembly needs.

We specialize in customizing PCB Mount Pin Headers, Female Pin Header Connectors, and Right Angle Pin Headers to meet your specific requirements. With a minimum order quantity of 1000PCS and a competitive price of 0.0001 per piece, we provide excellent value for high-volume production.

The connectors feature insulators made from premium materials such as LCP, Nylon, PA6T, or PBT+30% Glass Fiber (UL94V-0), guaranteeing durability and flame resistance. The pins are crafted from high-quality Phosphor Bronze or Brass to ensure reliable electrical contact with a maximum contact resistance of 20 milliohms.

Our PIN Header Connectors offer a retention force of at least 700g and can withstand up to 100 cycles of durability testing, making them ideal for long-lasting applications.

Packaging options include Reel, Tube, Tray, or Polybag to suit your logistics preferences. We maintain a supply ability of 100,000PCS and a delivery time of 7 to 10 days, ensuring timely fulfillment of your orders.

We accept flexible payment terms including T/T, Western Union, and L/C to facilitate smooth transactions. Choose LP for your customized PCB Mount Pin Header, Female Pin Header Connector, and Right Angle Pin Header needs, and experience premium quality and service.
