High Temperature Thermoplastic Insulator Material IDC Ribbon Cable Socket Current Rating 1.0Amp Designed for and Connectivity

Product Description:

The IDC Socket / BOX Header is a versatile and reliable electrical connector designed to facilitate secure and efficient connections in a wide range of electronic applications. Known for its robust construction and ease of use, this connector series is ideal for both industrial and consumer electronics, offering excellent performance and durability. The IDC Socket / BOX Header is engineered to meet the demanding requirements of modern electronic systems, providing a dependable interface for signal and power transmission.

One of the key features of this IDC Socket / BOX Header product is its insulation displacement contact (IDC) termination method. This technique allows for quick and reliable connections without the need for stripping wires, significantly reducing assembly time and minimizing the risk of wiring errors. The IDC termination ensures a strong mechanical and electrical connection by firmly gripping the conductor within the insulation, which enhances the overall reliability and longevity of the connection. This makes the IDC Socket Header Connector an excellent choice for applications where rapid installation and maintenance are critical.

The IDC Connector Socket Header comes in a wide variety of configurations, with the number of positions ranging from 2 to 40. This extensive range allows designers and engineers to select the most suitable connector size for their specific application, whether it involves a simple two-wire connection or a complex multi-wire interface. The flexibility in positioning ensures that the IDC Socket Header Connector can accommodate varying signal and power requirements, making it a versatile solution for numerous electronic devices and systems.

In terms of electrical performance, the IDC Socket / BOX Header boasts a contact resistance of 20 milliohms maximum. This low contact resistance ensures minimal signal loss and efficient electrical conductivity, which is crucial for maintaining signal integrity and power efficiency in electronic circuits. Additionally, the connector is rated for a voltage of up to 250V AC/DC, making it suitable for a broad spectrum of applications, including those requiring moderate to high voltage levels. This rating ensures safe and reliable operation under various electrical conditions.

Compliance with industry standards and regulations is another important aspect of the IDC Socket Header Connector. This product meets RoHS requirements, ensuring that it is free from hazardous substances and environmentally friendly. Furthermore, it is UL Recognized, which guarantees that the connector adheres to stringent safety and quality standards as defined by Underwriters Laboratories. These certifications provide peace of mind to manufacturers and end-users alike, confirming that the IDC Connector Socket Header is both safe and sustainable.

The design of the Box Header IDC Connector emphasizes ease of integration and compatibility with a wide range of mating connectors and cables. Its compact form factor and standardized dimensions facilitate straightforward installation on printed circuit boards (PCBs), enabling seamless integration into existing designs. The robust housing protects the internal contacts from mechanical damage and environmental factors, thereby enhancing the durability and reliability of the connection over time.

In summary, the IDC Socket / BOX Header is an essential component for any application requiring a dependable, easy-to-use, and efficient electrical connection. Its insulation displacement contact termination, wide range of positions from 2 to 40, low contact resistance of 20 milliohms maximum, and a voltage rating of 250V AC/DC make it a highly adaptable and high-performance solution. Coupled with its compliance with RoHS and UL Recognized standards, the IDC Connector Socket Header and Box Header IDC Connector offer a trusted choice for engineers and designers seeking quality and reliability in their connector solutions.

Features:

• Product Name: IDC Socket / BOX Header
• Number of positions: 2 to 40
• Current Rating: 1.0 Amp
• Pitch options: 0.8mm, 1.0mm, 1.27mm, 2.0mm, 2.54mm
• Color: Black (standard)
• Termination Method: Insulation Displacement Contact (IDC)
• Features IDC Ribbon Cable Socket for reliable connections
• Includes IDC Socket Connector Assembly for easy installation
• Utilizes Insulation Displacement Contact Socket technology for efficient and secure termination

Technical Parameters:

Applications:

The LP-BX020 IDC Socket / BOX Header, manufactured by LP in China, is an advanced Insulation Displacement Connector Socket designed to meet the rigorous demands of modern electronic applications. Certified under ISO-9001:2000 and compliant with RoHS and UL Recognized standards, this product guarantees high quality, reliability, and safety. Its termination method utilizes Insulation Displacement Contact (IDC) technology, which ensures a secure and efficient connection without the need for wire stripping. The contact material is made of phosphor bronze, providing excellent conductivity and durability, while the insulator is crafted from high temperature thermoplastic capable of withstanding operating temperature ranges from -65°C to +125°C.

This IDC Socket Connector Assembly is ideal for use in various industrial and commercial scenarios where dependable electrical connections are critical. It is commonly applied in telecommunications equipment, computer hardware, automotive electronics, home appliances, and industrial control systems. The Insulation Displacement Crimp Socket design simplifies assembly processes, reduces installation time, and minimizes the risk of connection faults, making it the preferred choice for mass production environments and high-volume manufacturing.

With a minimum order quantity of 1000PCS and a competitive price of 0.0001 per unit, the LP-BX020 is well-suited for large-scale production runs. The product is available in multiple packaging options such as reel, tube, tray, and polybag, providing flexibility to meet diverse logistical and handling requirements. The supplier guarantees a delivery time of 7 to 10 days and supports various payment methods including T/T, Western Union, and L/C, ensuring smooth procurement and supply chain operations.

Thanks to its robust build and compliance with international standards, the LP-BX020 IDC Socket / BOX Header excels in harsh operating environments where temperature fluctuations and mechanical stresses are common. Its high-quality phosphor bronze contacts and high temperature thermoplastic insulator make it reliable for long-term use in applications ranging from consumer electronics to industrial automation. Whether used in prototype development or full-scale production, this IDC Socket Connector Assembly delivers consistent performance and enhances overall system reliability.
