Insulator Resistance 500Megohms Min FFC Flexible Flat Cable Connector with Phosphor Bronze Solder Tab Durable Electrical Connection

Product Description:

The FPC / FFC Connector is an essential component in modern electronic assemblies, designed to provide reliable and efficient connections between flexible printed circuits (FPC) and flexible flat cables (FFC). This connector is widely recognized for its versatility and high performance in various applications, making it a preferred choice for engineers and designers working with flexible electronic systems. Available in gray and black colors, the connector not only offers aesthetic flexibility but also ensures easy identification and integration within different electronic environments.

One of the standout features of this FPC Ribbon Cable Connector is its robust operating temperature range, which spans from -40°C to +105°C. This wide temperature tolerance makes it suitable for use in harsh environments, including automotive, industrial, and consumer electronics, where temperature fluctuations are common. Whether operating in cold outdoor conditions or high-heat indoor settings, the connector maintains stable performance and dependable connections, ensuring the longevity and reliability of the electronic device.

The contact resistance of this FPC Electronic Connector Type is maintained at a maximum of 20 milliohms, which is a critical parameter for ensuring signal integrity and minimizing power loss. Low contact resistance translates to better electrical conductivity, reducing the chance of signal degradation and enhancing overall system performance. This characteristic is particularly important in high-speed data transmission applications, where consistent and reliable electrical contact is paramount.

Constructed from high-quality copper alloy and phosphor bronze, the contact material of this FPC / FFC Connector is engineered for durability and excellent conductivity. Copper alloy provides superior electrical performance, while phosphor bronze contributes to mechanical strength and corrosion resistance. The combination of these materials ensures that the connector can withstand repeated mating cycles without significant wear or loss of electrical properties, making it an ideal choice for applications requiring frequent connections and disconnections.

The connector is available in two main types: Zero Insertion Force (ZIF) and Low Insertion Force (LIF). The ZIF type is designed to allow the FPC or FFC to be inserted with virtually no force, reducing the risk of damage to the flexible cable during assembly. This type is especially beneficial in delicate electronic devices where precision and reliability are critical. On the other hand, the LIF type offers a slightly higher insertion force, providing a secure connection that is still easy to engage and disengage. Both types are engineered to accommodate a range of pitch sizes and cable thicknesses, providing flexibility for diverse design requirements.

As an FFC Flexible Circuit Connector, this product supports a variety of flexible cable configurations, enabling compact and space-saving designs in electronic devices. Its design facilitates quick and secure connections, which helps in reducing assembly time and improving manufacturing efficiency. The connector's compatibility with standard FPC and FFC cables ensures seamless integration into existing designs, making it a versatile solution for many applications.

In summary, the FPC / FFC Connector is a high-performance, reliable, and versatile electronic connector that meets the demanding requirements of modern flexible circuit applications. Its gray and black color options, wide operating temperature range, low contact resistance, and high-quality contact materials make it suitable for a broad spectrum of industries and uses. Whether in consumer electronics, automotive systems, or industrial equipment, this FPC Ribbon Cable Connector and FPC Electronic Connector Type provides durable, efficient, and secure connections for flexible cables, ensuring optimal device functionality and longevity.

Features:

• Product Name: FPC / FFC Connector
• Types: FPC Ribbon Cable Connector, FPC Electronic Connector Type, Flat Printed Cable Connector
• Plating Options: Gold Plating or Tin Plated
• Mounting Types: Surface Mount Technology (SMT) and Through Hole Technology (THT)
• Color Variants: Gray and Black
• Contact Resistance: Maximum 20mΩ
• Current Rating: 0.5 Amps

Technical Parameters:

Applications:

The LP-FPC030 is a high-quality FPC electronic connector type designed to meet the demanding requirements of modern electronic devices. Manufactured in China and certified with ISO-9001:2000, this flexible printed circuit connector ensures reliable and durable performance across various applications. With a pitch range of 0.5mm, 1.0mm, 1.25mm, and 1.27mm, it accommodates different design specifications, making it highly versatile for numerous electronic assembly scenarios.

One of the primary application occasions for the LP-FPC030 flat flexible cable connector is in consumer electronics such as smartphones, tablets, and laptops. Its compact size and excellent conductivity, thanks to contact materials made from copper alloy and phosphor bronze, make it ideal for connecting flexible printed circuits within tight spaces. The insulation materials, including LCP (Liquid Crystal Polymer) and Nylon 6T UL94V-0, provide high thermal stability and flame retardance, supporting reliable operation in devices subjected to varying temperatures between -40°C and +105°C.

In addition to consumer gadgets, the LP-FPC030 connector finds extensive use in automotive electronics. Modern vehicles rely heavily on flexible printed circuit connectors for infotainment systems, instrument clusters, and various sensor interfaces. The robust build quality and excellent electrical properties of this connector ensure it can withstand the harsh operating environments typical of automotive applications, including temperature fluctuations and vibrations.

The medical equipment industry also benefits from the LP-FPC030 flexible printed circuit connector. Its precision and durability are critical in devices such as diagnostic machines, portable monitoring systems, and handheld medical instruments where reliable electronic connections are vital for patient safety and accurate data transmission. The availability of packaging options like reels and tubes supports efficient manufacturing processes and inventory management for large-scale production runs.

Furthermore, industrial automation and robotics applications leverage the LP-FPC030 FPC electronic connector type for flexible and compact cable connections within control panels, sensors, and actuators. The connector's compliance with RoHS standards assures environmentally friendly manufacturing, aligning with industry regulations and sustainability goals.

With a minimum order quantity of 1000PCS and competitive pricing at $0.03 per unit, the LP-FPC030 flat flexible cable connector is an economical choice for manufacturers aiming to optimize cost without compromising quality. The supply ability of 100,000PCS and delivery time of 8 to 12 days ensures timely availability for project deadlines. Payment terms including T/T, Western Union, and L/C facilitate smooth international transactions, making this flexible printed circuit connector an excellent solution for global electronic manufacturing needs.

Customization:

LP brand offers high-quality FPC / FFC Connector, model number LP-FPC030, manufactured in China with ISO-9001:2000 certification. Our FFC Flexible Circuit Connector is designed to meet diverse application needs with a number of positions ranging from 2 to 50 pins, ensuring compatibility and flexibility.

We specialize in product customization services for FFC Flexible Flat Cable Connector, providing tailored solutions to fit your precise requirements. Our connectors feature an insulator resistance of 500 Megohms minimum and can withstand a maximum processing temperature of 230°C for 30 to 60 seconds, or 260°C for 10 seconds, ensuring reliable performance under various operating conditions.

Our Flexible Flat Cable Interface supports operating temperatures from -40°C to +105°C and is available with Surface Mount Technology (SMT) or Through Hole Technology (THT) mounting types, catering to different assembly processes.

With a minimum order quantity of 1000PCS and a competitive price of $0.03 per piece, we provide packaging options including reels and tubes to suit your logistics needs. Our supply ability is up to 100,000PCS, and delivery time ranges from 8 to 12 days, ensuring timely fulfillment of your orders.

We accept flexible payment terms such as T/T, Western Union, and L/C to facilitate smooth transactions. Trust LP for customized FFC Flexible Circuit Connector solutions that combine quality, reliability, and cost-effectiveness.
