Nickel Plating Dual Row Pin Header 1.0AMP Current Rating Versatile Connector Compatible with Multiple Electronic Systems

Product Description:

The PIN Header Connector is a versatile and reliable component designed to meet the demanding requirements of modern electronic assemblies. This connector is available in various configurations, including the Right Angle Pin Header, Dual Row Pin Header, and Through Hole Pin Header, making it suitable for a wide range of applications in circuit board design and electronic device manufacturing.

One of the key features of this PIN Header Connector is its excellent dielectric withstanding capability, rated at AC 500V. This ensures that the connector can withstand high voltage stress without breakdown, providing robust electrical isolation between pins and maintaining the integrity of the electrical connection under demanding conditions.

In terms of insulation performance, the connector offers an outstanding insulation resistance of 5000 megaohms minimum, significantly surpassing typical industry standards. This high insulation resistance guarantees minimal leakage current and enhances the overall reliability and safety of the electronic system in which it is used. Additionally, the insulation resistance is also specified at 1000 megaohms minimum under different testing conditions, further emphasizing its superior insulating properties.

The PIN Header Connector is engineered with a retention force of 700 grams minimum, ensuring a secure and stable connection once mated with corresponding components. This retention force is critical for maintaining consistent electrical contact, preventing accidental disconnections, and enhancing the durability of the connection during mechanical vibrations or handling.

Another notable attribute of this connector is the availability of multiple plastics heights, including 1.0mm, 1.5mm, 2.0mm, 2.5mm, and the standard 2.54mm. This range of options allows designers to select the appropriate height to fit their specific PCB layout requirements, optimizing space utilization and mechanical compatibility. The plastic insulator not only provides mechanical support but also contributes to the overall electrical insulation and durability of the connector.

The Right Angle Pin Header configuration is particularly useful for applications where space constraints require the connector to be mounted parallel to the PCB surface, facilitating compact designs and easier cable routing. The Dual Row Pin Header offers increased pin density by arranging the pins in two parallel rows, ideal for applications requiring multiple signal connections within a limited footprint. The Through Hole Pin Header provides robust mechanical stability by inserting pins through the PCB and soldering them on the opposite side, making it suitable for applications subjected to mechanical stress or thermal cycling.

Overall, the PIN Header Connector combines excellent electrical performance, mechanical robustness, and design flexibility. Its high dielectric withstanding voltage, superior insulation resistance, and strong retention force ensure reliable and long-lasting connections in a variety of electronic applications. Whether used as a Right Angle Pin Header, Dual Row Pin Header, or Through Hole Pin Header, this connector is engineered to meet the highest standards of quality and performance, making it an ideal choice for engineers and designers seeking dependable connectivity solutions.

Features:

• Product Name: PIN Header Connector
• Gender: Male
• Durability: 100 cycles
• Number of Pins: 2 to 40 pins
• Plating Options: Gold, Tin, Nickel
• Contact Resistance: 20M Ohms Max
• Available in Right Angle Pin Header and Straight Pin Header Connector configurations
• Reliable electrical connection for various electronic applications
• Suitable for use in high-density PCB layouts

Technical Parameters:

Applications:

The LP-P066 PIN Header Connector, proudly manufactured in China by the reputable LP brand, is a versatile and reliable component widely used in various electronic applications. Certified under ISO-9001:2000, this connector guarantees high-quality standards and consistent performance, making it an ideal choice for both industrial and consumer electronics. With a supply ability of 1,000,000PCS and a minimum order quantity of 1000PCS, it is readily available for large-scale production needs.

This product features a range of pin counts from 2 to 40 pins, accommodating diverse circuit designs. The plastics height options of 1.0mm, 1.5mm, 2.0mm, 2.5mm, and 2.54mm provide flexibility in mounting and spacing requirements. Constructed with durable phosphor bronze or brass pin materials, the connector ensures excellent conductivity and mechanical strength. It is designed to operate efficiently within a temperature range of -65°C to +125°C and withstands processing temperatures up to 260℃ for 10 seconds, making it suitable for demanding environments.

The LP-P066 PIN Header Connector is commonly used as a Through Hole Pin Header, offering robust mechanical stability for PCB assemblies. Its PCB Mount Pin Header configuration facilitates easy integration onto printed circuit boards, enhancing manufacturing efficiency and reliability. Additionally, the Dual Row Pin Header variant is perfect for applications requiring higher pin density and compact layouts, such as in communication devices, industrial control systems, and computer hardware.

This connector’s packaging options include Reel, Tube, Tray, and Polybag, allowing for convenient handling and storage based on customer requirements. With a competitive price point of 0.0001 per unit and flexible payment terms including T/T, Western Union, and L/C, LP ensures customer satisfaction in both cost and service. Delivery time is typically within 7 to 10 days, supporting timely project execution.

In practical applications, the LP-P066 PIN Header Connector is ideal for use in embedded systems, microcontroller boards, sensors, and interface modules. Its reliable electrical connection and mechanical durability make it suitable for automotive electronics, consumer gadgets, industrial machinery, and telecommunications equipment. Whether used as a Through Hole Pin Header for secure PCB attachment, a PCB Mount Pin Header for versatile circuit design, or a Dual Row Pin Header for compact multi-pin connections, this connector meets the rigorous demands of modern electronics manufacturing.

Customization:

Introducing the LP brand PIN Header Connector, model number LP-P066, proudly manufactured in China with ISO-9001:2000 certification ensuring top quality. We offer product customization services tailored to your specific needs with a minimum order quantity of 1000PCS.

Our PIN Header Connectors are available in a wide range of pin numbers from 2 to 40 pins, accommodating various application requirements. You can choose from multiple pitch options including 0.8mm, 1.0mm, 1.27mm, 2.0mm, and 2.54mm, providing flexibility in design and compatibility.

The connectors feature copper alloy contacts for excellent conductivity and durability, with a retention force of 700g minimum to ensure reliable connections. Our product line includes popular styles such as Dual Row Pin Header and Right Angle Pin Header, perfect for diverse electronic assemblies.

Packaging options include Reel, Tube, Tray, and Polybag to suit your inventory and handling preferences. We guarantee a swift delivery time of 7 to 10 days, supported by a robust supply ability of 1,000,000PCS to meet large scale demands.

Pricing is extremely competitive at 0.0001 per unit, with flexible payment terms including T/T, Western Union, and L/C to facilitate smooth transactions. Trust LP for high-quality PIN Header Connectors customized to your exact specifications, including Right Angle Pin Header configurations, ensuring optimal performance in your projects.

Contact us today to customize your PIN Header Connector order and experience premium service and product excellence.

Support and Services:

Our PIN Header Connector product is supported by a dedicated technical support team to ensure seamless integration and optimal performance. We provide comprehensive assistance including product selection guidance, installation instructions, troubleshooting tips, and customization options to meet specific application needs.

Technical documentation, including datasheets, application notes, and wiring diagrams, is available to help you understand the specifications and proper usage of the PIN Header Connector. Our experts are ready to assist with compatibility questions and design recommendations to enhance your project’s reliability and efficiency.

Additionally, we offer repair and maintenance services to extend the lifespan of your PIN Header Connectors. For bulk orders or specialized requirements, consult our support team to explore customized solutions and pricing options tailored to your business needs.

We are committed to providing timely and effective support to ensure your satisfaction and success when using our PIN Header Connector products.

Packing and Shipping:

Our PIN Header Connector is carefully packaged to ensure maximum protection during transit. Each connector is placed in an anti-static bag to prevent any electrostatic discharge damage. Multiple units are then securely packed in sturdy, cushioned boxes to avoid any physical impact or deformation.

For shipping, we offer various options including standard ground, expedited, and international delivery services. All shipments are tracked and insured to provide peace of mind and reliable delivery. We take every precaution to ensure your PIN Header Connector arrives safely and on time.
