Insulation Resistance 1000M Ohms Min Single Row Pin Connector Connector for Electrical Connections in Automation Equipment

Product Description:

The PIN Header Connector is a versatile and essential component widely used in electronic circuits and devices for establishing reliable electrical connections. Designed to serve as a PCB Mount Pin Header, this product offers a range of configurations and specifications that cater to diverse application needs, ensuring compatibility and performance across various electronic assemblies.

One of the key features of this PIN Header Connector is its availability in multiple plastics height options, including 1.0mm, 1.5mm, 2.0mm, 2.5mm, and 2.54mm. This variety allows designers and engineers to select the precise height that best fits their PCB layout and mechanical design requirements, ensuring optimal clearance and mechanical stability. The carefully chosen plastic materials provide excellent insulation and durability, contributing to the overall reliability of the connector in different operating environments.

The PIN Header Connector is offered in several types to accommodate different mounting and connection preferences. These types include Vertical, Right Angle, SMT (Surface Mount Technology), Single Row, Double Row, and even Three Rows configurations. The Vertical and Right Angle Pin Header options are particularly popular for their ease of integration on printed circuit boards, with the Right Angle Pin Header enabling connections parallel to the PCB surface, which is ideal for saving space and achieving compact device designs. SMT variants facilitate automated assembly processes, improving production efficiency and consistency.

Constructed with high-quality pin materials, the PIN Header Connector features pins made from either Phosphor Bronze or Brass. Both materials are chosen for their excellent electrical conductivity, mechanical strength, and resistance to corrosion, ensuring long-lasting performance and stable electrical connections. Phosphor Bronze pins are known for their superior resilience and spring properties, making them suitable for applications requiring repeated mating cycles. Brass pins, on the other hand, offer good conductivity and cost-effectiveness, making them a preferred choice in many standard applications.

In terms of electrical performance, this connector supports current ratings of either 1.0 AMP or 3.0 AMP, depending on the specific model and configuration. This range makes it suitable for a wide variety of low to moderate power applications, from signal transmission to power distribution within electronic devices. The current rating ensures safe and reliable operation under normal usage conditions, preventing overheating and maintaining signal integrity.

The PIN Header Connector is designed with a male gender configuration, providing a reliable male interface for mating with female connectors, sockets, or cables. This male gender design is standard in many electronic assemblies, facilitating easy and secure connections with complementary components. The robust construction of the male pins ensures firm insertion and retention, minimizing the risk of disconnection due to vibration or mechanical stress.

Overall, the PIN Header Connector stands out as a high-quality, adaptable, and dependable solution for PCB interconnections. Whether you require a PCB Mount Pin Header for straightforward vertical mounting, a Right Angle Pin Header for space-saving designs, or an SMT variant for automated assembly, this product series offers the flexibility to meet your project's demands. Its variety in plastics height, pin material, row configuration, and current rating makes it an ideal choice for engineers and designers aiming to achieve efficient, durable, and effective electronic connections in their devices.

Features:

• Product Name: PIN Header Connector
• Durability: 100 cycles for long-lasting performance
• Insulator Materials: LCP, Nylon, PA6T, PBT+30% Glass Fiber (UL94V-0 rated)
• Fire Protection Grade: UL94V-0 ensuring high safety standards
• Gender: Male pin configuration
• Dielectric Withstanding Voltage: AC 500V for reliable insulation
• Available in Dual Row Pin Header and Right Angle Pin Header styles
• Compatible with Female Pin Header Connector counterparts

Technical Parameters:

Applications:

The LP-P064 Pin Header Connector, manufactured by the reputable brand LP in China and certified under ISO-9001:2000, is a highly versatile and reliable component widely used in various electronic and electrical applications. Its exceptional quality and design make it an ideal choice for PCB Mount Pin Header requirements across diverse industries. With a supply ability of 1,000,000PCS and a minimum order quantity of 1000PCS, this product ensures availability for large-scale manufacturing and production needs.

This Pin Header Connector is designed with a range of pitch options including 0.8mm, 1.0mm, 1.27mm, 2.0mm, and 2.54mm, accommodating different spacing requirements for circuit boards. The dual row pin header configuration offers enhanced connectivity and stability, making it suitable for complex and compact PCB layouts. Crafted from high-quality phosphor bronze or brass pin materials, the connector guarantees excellent electrical conductivity and mechanical strength, ensuring long-lasting performance even under demanding conditions.

With a dielectric strength of 1000 V AC minimum and operation temperature range from -65°C to +125°C, the LP-P064 Pin Header Connector is well-suited for use in environments that require high durability and reliability. Its robust construction and thermal tolerance make it perfect for applications in automotive electronics, industrial machinery, telecommunications equipment, and consumer electronics, where consistent electrical connections are critical.

The packaging options, including reel, tube, tray, and polybag, provide flexibility and convenience for various assembly processes, whether automated or manual. Additionally, the product is packed in sturdy carton boxes to ensure safe transportation and storage. The delivery time of 7 to 10 days supports efficient project timelines, while the flexible payment terms such as T/T, Western Union, and L/C facilitate smooth transactions.

In summary, the LP-P064 PCB Mount Pin Header and Dual Row Pin Header connector is ideal for application occasions that demand high precision, durability, and reliable electrical performance. It is commonly used in printed circuit board assemblies, industrial control systems, communication devices, and consumer electronics, offering a cost-effective and high-quality solution for engineers and manufacturers worldwide.

Customization:

Our PIN Header Connector product, model number LP-P064 from the trusted LP brand, offers extensive customization services to meet your specific needs. Manufactured in China and certified with ISO-9001:2000, this connector ensures high quality and reliability for your applications.

We provide customization options for Surface Mount Pin Header, Straight Pin Header Connector, and Through Hole Pin Header types to suit various mounting and design requirements. The insulator materials available include LCP, NYLON, PA6T, and PBT+30% glass fiber, all meeting the UL94V-0 fire protection grade for safety and durability.

The plastics height can be customized to 1.0mm, 1.5mm, 2.0mm, 2.5mm, or 2.54mm based on your project specifications. Our connectors feature a maximum contact resistance of 20M Ohms and withstand dielectric strength up to AC 500V, ensuring excellent electrical performance.

We offer flexible packaging options including Reel, Tube, Tray, and Polybag, with a minimum order quantity of 1000PCS and a competitive price starting at 0.0001 per unit. Our supply ability reaches up to 1,000,000PCS with a delivery time of 7 to 10 days.

Payment terms are convenient and secure, supporting T/T, Western Union, and L/C methods. Choose LP-P064 for your pin header connector needs and enjoy professional product customization services tailored to your exact requirements.
