2 To 40 Pins Single Row Pin Connector Capable of Processing Temperature 260C For 10 Seconds Ensuring Signal Transmission

Product Description:

The Female Pin Header Connector is a highly reliable and versatile component designed for a wide range of electronic applications. Crafted with precision, this connector features contacts made from high-quality copper alloys, ensuring excellent electrical conductivity and durability. The use of copper alloys in the contact material not only provides superior performance but also enhances corrosion resistance, making the connector suitable for demanding environments and long-term usage.

One of the key advantages of this Female Pin Header Connector is its robust processing temperature capability. It can withstand a processing temperature of 260℃ for up to 10 seconds, which makes it compatible with various soldering techniques and manufacturing processes. This high thermal tolerance ensures that the connector maintains its structural integrity and electrical performance even during intense soldering operations, providing a reliable connection in printed circuit board (PCB) assemblies.

Durability is a critical factor in connector performance, and this product excels with a tested durability of 100 cycles. This means the connector can endure repeated mating and unmating cycles without compromising its mechanical stability or electrical continuity. Such durability is essential for applications where connectors are frequently connected and disconnected, ensuring consistent performance throughout the product’s lifecycle.

The Female Pin Header Connector is available with a range of plastic heights to accommodate different design requirements. The plastics height options include 1.0mm, 1.5mm, 2.0mm, 2.5mm, and the standard 2.54mm. This variety allows engineers and designers to select the most appropriate size for their specific application, ensuring optimal fit and function within their electronic assemblies. The availability of multiple heights also facilitates compatibility with various PCB layouts and device configurations.

In terms of materials, the insulator used in this Female Pin Header Connector is made from high-quality engineering plastics. Options include Liquid Crystal Polymer (LCP), Nylon, PA6T, and PBT reinforced with 30% glass fiber (PBT+30%G.F), all of which meet the stringent UL94V-0 flammability rating. This ensures that the connector is not only mechanically robust but also safe and compliant with industry standards for fire resistance. The use of these advanced insulator materials contributes to the overall reliability and longevity of the connector in diverse operating conditions.

This Female Pin Header Connector is designed as a Through Hole Pin Header, which means it is intended to be mounted by inserting its pins through holes drilled in the PCB and soldered on the opposite side. Through hole mounting provides strong mechanical bonds and is often preferred in applications where the connector may be subjected to mechanical stress or where a secure, permanent connection is required.

Overall, the Female Pin Header Connector combines excellent electrical properties, mechanical durability, and flexible design options, making it an ideal choice for a broad spectrum of electronic devices and systems. Whether you are designing consumer electronics, industrial equipment, or communication devices, this connector offers a dependable solution that ensures reliable connections and long-term performance. Its combination of copper alloy contacts, high processing temperature tolerance, multiple plastic height options, and superior insulator materials sets it apart in the market as a top-tier Through Hole Pin Header option.

Features:

• Product Name: PIN Header Connector
• Available Types: Vertical, Right Angle, SMT
• Configurations: Single Row, Double Row, Three Rows
• Insulation Resistance: 1000M Ohms Min
• Current Rating Options: 1.0AMP or 3.0AMP
• Retention Force: 700g Min
• Gender: Male
• Includes Single Row Pin Connector for versatile applications
• Through Hole Pin Header available for secure PCB mounting
• Dual Row Pin Header option for increased pin density

Technical Parameters:

Applications:

The Loupeng PIN Header Connector, model number LP-P084, is a high-quality Surface Mount Pin Header designed to meet the rigorous demands of modern electronic applications. Manufactured in China and certified under ISO-9001:2000, this connector ensures reliable performance and durability. Its robust construction includes an insulator made from premium materials such as LCP, Nylon, PA6T, or PBT with 30% glass fiber reinforcement (UL94V-0), providing excellent insulation resistance of at least 1000M Ohms. The connector's plating options, including gold, tin, and nickel, offer superior conductivity and corrosion resistance, with a maximum contact resistance of 20 milliohms, making it ideal for sensitive electronic circuits.

Designed as a Single Row Pin Connector, the LP-P084 is widely used in a variety of electronic devices and systems where compact and efficient connections are required. Its retention force of 700g minimum ensures a secure and stable connection, which is critical in environments subject to vibration or movement. This Male Pin Header Connector is perfect for applications such as PCB interconnections, industrial control systems, communication devices, and consumer electronics, where reliable pin-to-board connections are essential.

The product is available in multiple convenient packaging options, including reel, tube, tray, and polybag, catering to different assembly and manufacturing needs. With a minimum order quantity of 1000 pieces and an impressive supply ability of 1,000,000 pieces, Loupeng guarantees steady availability and competitive pricing starting at just 0.0001 per unit. Delivery is prompt, typically within 7 to 10 days, and payment terms are flexible, supporting T/T and L/C methods.

In summary, the Loupeng LP-P084 Surface Mount Pin Header is an excellent choice for engineers and manufacturers seeking a reliable, cost-effective Male Pin Header Connector. Its high retention force, superior insulation, and low contact resistance make it suitable for a broad range of occasions and scenarios, including industrial automation, telecommunications, consumer electronics, and automotive electronics. Whether used in prototype development or mass production, this connector delivers consistent performance and long-term reliability, making it an indispensable component in modern electronic assembly.

Customization:

Loupeng offers customizable PCB Mount Pin Header solutions with model number LP-P084, proudly manufactured in China and certified with ISO-9001:2000. Our Single Row Pin Connector products feature a variety of pitches including 0.8mm, 1.0mm, 1.27mm, 2.0mm, and 2.54mm, catering to diverse design requirements.

We provide high-quality insulators made from LCP, Nylon, PA6T, and PBT+30% Glass Fiber (UL94V-0), ensuring durability and reliable performance. The PCB Mount Pin Header connectors support current ratings of 1.0AMP or 3.0AMP with a retention force of at least 700g, making them suitable for robust electronic applications.

Our standard packaging options include Reel, Tube, Tray, and Polybag, all packed securely in carton boxes for safe delivery. With a minimum order quantity of 1000PCS and a supply ability of 1,000,000PCS, we guarantee competitive pricing starting at 0.0001 per piece and prompt delivery within 7 to 10 days.

Flexible payment terms such as T/T and L/C are available to accommodate your purchasing preferences. Trust Loupeng for your PCB Mount Pin Header and Single Row Pin Connector needs, combining quality, efficiency, and customization to meet your specific project demands.
