Office Equipment Board To Board Connector with Signal Pin Contact Resistance 50mΩ Max and Current Rating Up To 3A Per Contact

Product Description:

The Board To Board Connector is an essential component in modern electronic assemblies, providing a reliable and efficient means to connect two printed circuit boards (PCBs) together. Designed as a Board Mount Connector System, this product offers superior performance and versatility, making it an ideal choice for a wide range of applications including consumer electronics, industrial equipment, telecommunications, and automotive systems.

This connector features a Dual Row Board Connector configuration, which allows for a higher density of connections within a compact footprint. The dual row design not only maximizes the number of contact points but also enhances signal integrity and mechanical stability. This makes it particularly suitable for complex circuits where space-saving and reliable connectivity are critical.

One of the standout features of this Board To Board Connector is its Surface Mount Board Connector capability. The surface mount technology (SMT) design facilitates easy and precise placement on PCBs using automated assembly processes. This ensures high production efficiency and consistent quality, reducing manufacturing costs and improving overall product reliability.

In terms of physical characteristics, this connector is available in multiple plastic heights to accommodate different design requirements. The plastic height options include H=5.0mm, 3.0mm, 1.28mm, 1.5mm, 2.0mm, 2.5mm, 3.7mm, 7.7mm, 6.0mm, 6.5mm, 6.6mm, 7.0mm, 4.0mm, 3.3mm, 7.8mm, 9.75mm, and 14.5mm. This wide range of heights allows designers to select the perfect connector size that matches their PCB layout and mechanical constraints, ensuring optimal fit and performance.

Durability and electrical performance are paramount in any connector system. This Board To Board Connector meets rigorous standards with a dielectric withstanding voltage of 250V AC for one minute. This means it can reliably insulate and protect circuits from electrical breakdown under high voltage conditions, ensuring safety and long-term functionality of the device it is incorporated into.

Another critical mechanical parameter is the insertion force. This connector boasts a maximum insertion force of 1.5N per pin, with a total maximum insertion force capped at 40N. Such low insertion force requirements facilitate easy mating and unmating of the connectors during assembly or maintenance, minimizing the risk of damage to the PCB or connector contacts. This feature is particularly advantageous in applications where connectors may be frequently connected and disconnected.

For packaging and logistics, the Board To Board Connector is supplied in reels, which is the preferred packaging method for automated assembly lines. Reel packaging ensures that the connectors are delivered in a continuous strip, allowing machines to efficiently pick and place them onto PCBs, thereby streamlining the production process.

When it comes to delivery, multiple shipping options are available to meet different customer needs. The product can be shipped via air shipment, sea shipment, as well as through reliable courier services such as UPS, FEDEX, and DHL. This flexibility in delivery methods ensures that customers can receive their orders promptly and according to their logistical preferences.

In summary, the Board To Board Connector offers an advanced Board Mount Connector System featuring a Dual Row Board Connector layout and Surface Mount Board Connector technology. With a broad selection of plastic heights, excellent dielectric strength, low insertion force, and convenient reel packaging, it stands out as a dependable and versatile solution for connecting PCBs. Its compatibility with diverse shipping methods further enhances its appeal to manufacturers worldwide seeking high-quality, efficient, and reliable interconnection solutions.

Features:

• Product Name: Board To Board Connector
• Electrical Board Connection Interface
• PCB Board Interconnect Connector
• Dual Row Board Connector with 2 rows
• Insulator Material: Polyester
• Dielectric Withstanding Voltage: 250V AC for one minute
• Trial Order Quantity: 2000 Pcs
• FOB Price: Get Latest Price

Technical Parameters:

Applications:

The Loupeng LP-BTB023 Board To Board Connector is a highly reliable and versatile component designed for various electronic assembly applications. As a premium Stackable Board Connector Assembly, it offers excellent performance in connecting multiple printed circuit boards (PCBs) efficiently and securely. Manufactured in China under the strict quality management system certified by ISO-9001:2000, this connector ensures consistent quality and durability suitable for demanding industrial environments.

This Dual Row Board Connector is engineered with a robust housing material made of LCP UL94V-0, providing exceptional flame retardancy and mechanical strength. The connector supports an ambient temperature range from -55ºC to +125ºC, making it ideal for use across a wide array of temperature-sensitive applications. Its insertion force is optimized at 1.5N per pin, with a maximum total force of 40N, ensuring smooth mating and unmating without damage to the pins or boards.

The LP-BTB023 model is available in packaging options including reel, tube, and tray, facilitating easy handling and automated assembly processes. With a supply ability of 100,000 pieces and a minimum order quantity of 1000PCS, Loupeng caters to both small and large-scale production demands. The typical delivery time is 7 to 10 days, with flexible payment terms such as T/T and L/C, ensuring a smooth procurement experience for manufacturers worldwide.

This Through Hole Board Connector is widely used in industries such as telecommunications, consumer electronics, automotive electronics, industrial control systems, and medical devices. Its stackable design allows for compact and efficient board-to-board connections in multi-layered PCB assemblies, enhancing signal integrity and mechanical stability. The connector’s dual row configuration supports high pin counts in a small footprint, making it suitable for complex circuit designs requiring reliable electrical contact.

Overall, the Loupeng LP-BTB023 Board To Board Connector is an excellent choice for engineers and manufacturers seeking a cost-effective, durable, and high-performance interconnect solution. With a competitive FOB price starting at $0.06 per unit, it combines affordability with quality, backed by Loupeng’s commitment to customer satisfaction and technical excellence. Whether used in prototyping or full-scale production, this connector ensures dependable connectivity under various environmental and operational conditions.

Customization:

Loupeng offers the LP-BTB023 model, a high-quality Surface Mount Board Connector designed to meet various electronic assembly needs. This Printed Circuit Board Connector features a Dual Row Board Connector configuration, ensuring reliable connections with a current rating of up to 3A per contact.

Manufactured in China, the LP-BTB023 is made with premium materials including copper alloy terminals and posts with gold plating over nickel, providing excellent conductivity and corrosion resistance. The insulator is crafted from durable polyester, ensuring stable performance.

Certified under ISO-9001:2000, this board to board connector guarantees quality and consistency. It has a minimum withdrawal force of 0.15N per pin and a durability rating of at least 30 cycles, making it suitable for repeated use in various applications.

Packaging options for the LP-BTB023 include reel, tube, and tray formats, catering to different production requirements. With a supply ability of 100,000 PCS and a minimum order quantity of 1,000 PCS, Loupeng ensures prompt delivery within 7 to 10 days.

Competitive pricing at $0.06 per unit combined with flexible payment terms such as T/T and L/C make this connector an excellent choice for your manufacturing needs.
