Connector insertion force at a maximum rate of 12.5mm per minute USB Connector copper alloy gold plating overall pull out force 1.02kgf MIN

Product Description:

The Male Female USB Connector is a highly reliable and versatile component designed to facilitate seamless data transfer and connectivity across a wide range of electronic devices. As a Universal Serial Bus Connector, it is engineered to meet the demands of modern technology, ensuring robust performance and long-lasting durability. This connector is ideal for applications requiring a compact USB connection interface, making it an essential part of your electronic assembly or device integration projects.

One of the key features of this USB Connector is its optimal connector insertion force, which ranges from 5 to 20 Newtons, measured at a maximum rate of 12.5 millimeters per minute. This precise insertion force ensures that the connector fits securely into its counterpart without causing damage to the pins or the housing, thereby maintaining a reliable connection throughout its usage. The carefully controlled insertion force also contributes to the ease of use, enabling smooth and consistent mating and unmating cycles.

Durability is a critical factor in the design of this Male Female USB Connector. It is rated for an impressive 10,000 cycles, which means it can withstand repeated plugging and unplugging without any degradation in performance or physical integrity. This high cycle life ensures that the connector remains dependable over extended periods, even in demanding environments where frequent connections and disconnections are necessary. Such durability makes it an excellent choice for both consumer electronics and industrial applications.

Electrical performance is another vital aspect of this USB Data Transfer Connector. It boasts an insulator resistance of at least 1000 megaohms, which guarantees excellent insulation between the conductive elements. This high insulator resistance minimizes the risk of short circuits and signal interference, ensuring stable and efficient data transmission. Whether you are transferring files, streaming media, or synchronizing devices, this connector maintains the integrity of your data signals.

In addition to electrical reliability, the Male Female USB Connector is designed to withstand mechanical stresses. It features an overall pull-out force of at least 1.02 kilograms-force, providing a secure locking mechanism that prevents accidental disconnection. This pull-out force ensures that the connection remains intact during normal use, preventing data loss or communication interruptions caused by loose or disconnected cables.

The compact design of this USB connection interface makes it suitable for integration into a variety of devices, including laptops, desktops, peripheral devices, and embedded systems. Its small footprint allows manufacturers to save space without compromising on connectivity performance. This makes it a preferred choice for modern electronic devices that demand both functionality and space efficiency.

In summary, the Male Female USB Connector is a robust and dependable Universal Serial Bus Connector that combines high durability, secure mechanical performance, and excellent electrical insulation. Its ability to endure 10,000 connection cycles, maintain a reliable insertion force, and provide strong pull-out resistance makes it an indispensable component for any application requiring a compact USB connection interface. Whether for data transfer, charging, or device synchronization, this USB Data Transfer Connector ensures optimal performance and reliability, meeting the standards of today’s fast-paced technological environment.

Features:

• Compact USB Connection Interface for efficient and reliable connectivity
• High insulation impedance of 100MΩ MIN at 250V DC ensuring safety and performance
• Connector extraction force ranging from 8 to 20N, tested at a maximum rate of 12.5mm per minute
• Selective plating on contacts for enhanced durability and conductivity
• Recommended IR Reflow process at 260°C for 3 to 5 seconds for optimal soldering
• Overall insertion force up to 3.57kgf MAX for secure connection
• Designed as a USB Communication Port Connector providing seamless data transfer
• Reliable USB Communication Port Connector suitable for various electronic devices

Technical Parameters:

Applications:

The LP brand USB Connector, model number LP-U047, is a high-quality Universal USB Interface Connector designed and manufactured in China with ISO-9001:2000 certification. This connector is ideal for a wide range of application occasions and scenarios where reliable and efficient data transfer and power delivery are essential. Thanks to its compact USB connection interface, the LP-U047 fits perfectly into various electronic devices, offering a Universal Serial Bus Connector solution that is both versatile and dependable.

In consumer electronics, the LP-U047 USB connector is widely used in devices such as smartphones, tablets, laptops, and peripheral accessories. Its compact size allows manufacturers to design slimmer, more portable products without compromising connectivity. The connector’s current rating of 1.5A to 5A supports efficient charging and data transfer, making it perfect for fast-charging USB ports and high-speed data communication in everyday gadgets.

In industrial and commercial environments, the LP-U047’s selective contact plating and robust overall insertion force of 3.57kgf max ensure durable and stable connections even in demanding conditions. This makes it suitable for use in embedded systems, medical devices, automotive electronics, and other equipment requiring reliable and long-lasting USB interfaces. The high insulator resistance of 1000MΩ minimum further guarantees safety and performance in sensitive electronic applications.

The connector’s compliance with RoHS and halogen-free standards reflects its environmentally friendly design, making it a preferred choice for companies committed to sustainability. Packaged in reels, tubes, or trays, the LP-U047 is convenient for mass production assembly lines, with a minimum order quantity of 1000PCS and a supply ability of up to 1,000,000PCS, ensuring availability for large-scale manufacturing projects.

With a competitive price of 0.01 per unit and flexible payment terms including T/T and L/C, the LP-U047 USB connector is a cost-effective solution for manufacturers seeking high-quality Universal Serial Bus Connectors. Its delivery time ranges from 7 to 10 days, enabling timely integration into production schedules.

Overall, the LP-U047 Universal USB Interface Connector is perfectly suited for a broad range of applications, from consumer electronics and industrial equipment to automotive and medical devices, wherever a compact USB connection interface with reliable performance and environmental compliance is required.

Customization:

LP offers comprehensive product customization services for the USB Connector, model number LP-U047, ensuring it meets your specific requirements. Manufactured in China and certified with ISO-9001:2000, this Universal Serial Bus Connector is designed for high reliability and performance.

Our USB Peripheral Connection Interface supports a minimum order quantity of 1000PCS, with a supply ability of up to 1,000,000PCS. The price is competitively set at 0.01 per unit, and packaging options include Reel, Tube, or Tray to suit your logistics needs.

The USB Connector features a dielectric withstanding voltage of 100 VRMS AC minimum, utilizing high-quality copper alloy with gold or nickel plating. The contacts are Au plated in 1U, 15U, or 30U variants, and the insulator material consists of PBT or LCP+30% glass fiber, compliant with UL94V-0 standards. The overall insertion force is capped at 3.57kgf max, ensuring ease of use and durability.

Delivery time ranges from 7 to 10 days, with flexible payment terms including T/T and L/C. Customize your Universal USB Interface Connector with LP to guarantee a tailored solution for your electronic applications.
