Withdrawal force 2.3kgf Max Mini PCIe Expansion Slot Incorporating Housing Material High Temperature Thermoplastic Suitable for Industrial

Product Description:

The MINI PCI-E Connector is a high-quality Mini PCI Express Socket designed to meet the demanding requirements of modern electronic devices. This connector is an essential component for securely interfacing Mini PCIe modules, providing reliable and stable connectivity for a wide range of applications including embedded systems, industrial equipment, telecommunications, and computing devices.

One of the standout features of this Mini PCI Express Socket is its integrated locking mechanism. This locking feature ensures that the Mini PCIe Module Connector maintains a secure connection even in environments subject to vibration or mechanical stress. The locking mechanism not only enhances the reliability of the connection but also simplifies the installation and removal process, making it highly user-friendly for technicians and engineers alike.

The MINI PCI-E Connector is engineered to operate efficiently within a broad temperature range, from -40°C to +85°C. This wide operating temperature range allows it to function reliably in harsh environmental conditions, including outdoor installations and industrial settings where temperature fluctuations are common. The robust thermal tolerance ensures that the connector maintains its performance and integrity, reducing the risk of failure due to thermal stress.

Contact resistance is a critical parameter for any connector, and this Mini PCI Express Socket excels in this regard with a maximum initial contact resistance of just 55 milliohms. Low contact resistance is crucial for maintaining signal integrity and minimizing power loss, which translates to improved performance and energy efficiency in connected devices. This characteristic makes the MINI PCI-E Connector an ideal choice for high-speed data transmission and sensitive electronic applications.

The housing of the MINI PCI-E Connector is constructed from high-temperature thermoplastic material rated UL94V-0. This flame-retardant material not only ensures safety by preventing the spread of fire but also provides excellent durability and resistance to wear and environmental factors. The high-temperature thermoplastic housing contributes to the overall robustness of the connector, making it suitable for use in demanding environments where reliability is paramount.

Designed with precision and quality in mind, this Mini PCI Express Socket supports the standard Mini PCIe Module form factors, ensuring compatibility with a wide range of devices and modules. Its compact design allows for efficient use of space on printed circuit boards (PCBs), making it ideal for compact and portable electronics where space-saving is critical.

In addition to its superior mechanical and electrical performance, the MINI PCI-E Connector is manufactured to meet strict industry standards, ensuring consistent quality and long-term reliability. Whether used in consumer electronics, industrial automation, networking equipment, or automotive applications, this Mini PCIe Module Connector delivers dependable performance and peace of mind.

Overall, the MINI PCI-E Connector stands out as a versatile and dependable Mini PCI Express Socket solution that combines a secure locking mechanism, wide operating temperature range, low contact resistance, and durable high-temperature thermoplastic housing. It is an excellent choice for anyone looking to ensure robust and reliable connections for Mini PCIe modules in challenging environments.

Features:

• Product Name: MINI PCI-E Connector
• Also known as Mini PCI-E Connector
• Ideal for Mini PCIe Module Connector applications
• Compatible with Mini PCI Express Slot and Mini PCIe Card Slot
• Contact Material: High-quality Copper Alloy for excellent conductivity
• Housing made of High Temperature Thermoplastic UL94V-0 for enhanced safety and durability
• Available Heights: 4.0mm, 5.2mm, 6.8mm, 7.0mm, 8.0mm, and 9.9mm
• Low Contact Resistance: 55 Milliohms Max (initial) ensuring reliable electrical performance

Technical Parameters:

This Mini PCI Express Slot, also known as Mini PCIe Socket Connector or Mini PCI-E Connector Slot, is designed for reliable performance in wireless modules and embedded systems.

Applications:

The LP-MP007 Mini PCIe Card Connector from brand LP is a highly reliable and versatile component designed to meet the demanding needs of modern electronic devices. Manufactured in China and certified with ISO-9001:2000, this connector ensures quality and consistency for various industrial and consumer applications. With a minimum order quantity of 1000PCS and a competitive price of 0.03 per unit, it is an ideal choice for large-scale production and integration projects.

This Mini PCIe Card Connector is available in multiple height options including 4.0mm, 5.2mm, 6.8mm, 7.0mm, 8.0mm, and 9.9mm, providing flexibility to fit different device designs and requirements. The housing is made from high-temperature thermoplastic UL94V-0, ensuring excellent durability and safety under harsh operating conditions. The connector offers a current rating of 0.5 AMP per contact, with contacts made from copper alloy featuring gold plating over nickel on the contact area and tin plating on the terminals to ensure optimal conductivity and corrosion resistance.

One of the key features of the LP-MP007 Mini PCIe Card Slot is its exceptional durability, capable of withstanding up to 500 insert and withdraw cycles, making it suitable for applications where frequent card replacement or maintenance is required. The product is packaged on reels for streamlined handling and automated assembly, with a supply ability of up to 100,000PCS and a delivery time of 7 to 10 days. Payment terms include T/T, Western Union, and L/C, catering to diverse business requirements.

The LP-MP007 Mini PCIe Socket Connector is widely used in various electronic devices such as laptops, embedded systems, network equipment, and industrial computers. It serves as a critical interface for Mini PCIe cards, enabling expansion and connectivity for wireless communication modules, SSDs, and other peripheral devices. Its robust design and reliable electrical performance make it ideal for both prototype development and mass production.

In summary, the LP brand’s Mini PCIe Card Connector LP-MP007 is perfectly suited for applications demanding high reliability, flexibility, and cost-effectiveness. Whether used in consumer electronics, industrial automation, or telecommunications, this Mini PCIe Card Slot ensures seamless integration and long-lasting performance, making it a trusted choice for engineers and manufacturers worldwide.

Customization:

Brand Name: LP

Model Number: LP-MP007

Place of Origin: China

Certification: ISO-9001:2000

Minimum Order Quantity: 1000PCS

Price: $0.03 per unit

Packaging Details: Reel packaging ensures safe and efficient delivery.

Delivery Time: 7~10 days

Payment Terms: T/T, Western Union, L/C

Supply Ability: 100000PCS

Pitch: 0.8mm

Application: Ideal for Wireless Modules and Embedded Systems.

Contact Material: Copper Alloy with Gold Plating over Nickel on contact area; Tin Plating on terminal for superior conductivity and durability.

With Locking Mechanism: Yes, providing secure connection and reliability.

Color: Black

Our MINI PCI-E Connector product, model LP-MP007 by LP, offers high-quality Mini PCI Express Socket and Mini PCI Express Connector solutions. This Mini PCIe Socket Connector is designed to meet the rigorous demands of wireless modules and embedded systems, ensuring excellent performance and durability. With ISO-9001:2000 certification and a strong supply ability, we guarantee timely delivery and quality assurance for your bulk orders.
