Contact Resistance 20M Ohms Max PIN Header Connector Number of Pins 2 to 40 Pins Insulator LCP NYLON PA6T PBT 30 Percent GF UL94V-0 Compact

Product Description:

The Single Row Pin Connector, commonly known as a Pin Header Connector, is a vital component widely used in electronic circuits and devices for establishing reliable electrical connections. Designed with precision and engineered for durability, this Pin Header Connector is an essential element for both prototyping and final product assembly, ensuring consistent performance across various applications.

One of the standout features of this Pin Header Connector is its impressive durability, rated for up to 100 cycles. This means the connector can withstand repeated mating and unmating processes without degradation in performance, making it ideal for applications where connectors need to be frequently connected and disconnected. This durability is crucial in maintaining reliable connections over time, reducing the risk of failure due to wear and tear.

The Pin Header Connector is manufactured to withstand a processing temperature of 260℃ for 10 seconds. This high-temperature tolerance ensures that the connector can endure the soldering process during PCB assembly without compromising its structural integrity or electrical properties. This capability is particularly important in automated manufacturing environments, where precision and reliability are paramount.

To enhance electrical conductivity and prevent corrosion, the pins of this Single Row Pin Connector are plated with high-quality materials such as gold, tin, or nickel. Each plating option offers unique benefits: gold plating provides excellent corrosion resistance and superior conductivity; tin plating offers cost-effectiveness with good solderability; and nickel plating delivers robust mechanical strength and corrosion protection. These plating options allow users to select the most suitable connector based on their specific application requirements.

The Pin Header Connector supports a range of current ratings, including 1.0 AMP and 3.0 AMP options, accommodating various power demands within electronic circuits. This flexibility makes the connector suitable for low-power signal transmission as well as moderate power delivery scenarios. Whether the application involves simple signal interfacing or powering small devices, the Pin Header Connector ensures stable and reliable current flow.

Available in configurations ranging from 2 to 40 pins, this Pin Header Connector offers versatility to meet diverse design needs. The variety in pin numbers allows engineers to choose connectors that fit the complexity and size of their circuits. Whether a compact 2-pin connector is needed for a simple connection or a larger 40-pin connector is required for complex multi-signal interfaces, this product line caters to a wide array of applications.

The Single Row Pin Connector's straightforward design simplifies PCB layout and wiring, reducing assembly time and minimizing the potential for errors. Its standardized pin spacing and robust construction make it easy to integrate into various electronic systems, from consumer electronics and industrial equipment to automotive and telecommunications devices.

In summary, the Pin Header Connector is a reliable, durable, and versatile component essential for establishing secure electrical connections in electronic assemblies. With a durability rating of 100 cycles, the ability to endure processing temperatures of 260℃ for 10 seconds, and plating options of gold, tin, or nickel, it ensures long-lasting performance. Supporting current ratings of 1.0 AMP or 3.0 AMP and available in pin counts from 2 to 40, this Single Row Pin Connector meets the demands of a wide range of electronic applications, delivering both quality and performance.

Features:

• Product Name: PIN Header Connector
• Type: Male Pin Header Connector
• Configuration: Single Row Pin Connector
• Contact Resistance: 20 milliohms max
• Pitch Options: 0.8mm, 1.0mm, 1.27mm, 2.0mm, 2.54mm
• Pin Numbers: 2 to 40 pins available
• Fire Protection Grade: UL94V-0
• Contact Material: Copper Alloys

Technical Parameters:

Applications:

The Loupeng LP-P079 PIN Header Connector is a versatile and reliable component widely used in various electronic applications. As a Single Row Pin Connector, it offers excellent performance and durability, making it an ideal choice for both industrial and consumer electronics. Its availability in multiple pitch options, including 0.8mm, 1.0mm, 1.27mm, 2.0mm, and 2.54mm, allows for flexible integration into different circuit board designs and ensures compatibility with a broad range of devices.

This Male Pin Header Connector is particularly suitable for applications requiring secure and stable electrical connections. With a retention force of 700g minimum, it guarantees firm mating with corresponding connectors, minimizing the risk of disconnection in high-vibration environments. The connector’s current rating of 1.0AMP or 3.0AMP and a contact resistance of 20M Ohms maximum further enhance its reliability in transmitting signals and power efficiently.

Thanks to its ISO-9001:2000 certification, the Loupeng LP-P079 ensures high-quality manufacturing standards and consistent product performance. It is widely used in telecommunications, computing, automotive electronics, industrial control systems, and consumer electronic devices. Whether in prototyping or mass production, the connector’s durability of 100 cycles makes it suitable for repeated mating and unmating without compromising connection integrity.

Packaging options such as reel, tube, tray, and polybag provide convenience for different assembly processes, supporting efficient handling and storage. The product’s supply ability of 1,000,000 PCS and a minimum order quantity of 1000 PCS make it an excellent choice for large-scale manufacturing projects. Delivery time is prompt, typically within 7 to 10 days, and flexible payment terms including T/T and L/C accommodate various purchasing preferences.

In summary, the Loupeng LP-P079 Single Row Pin Connector and Male Pin Header Connector represent an optimal solution for electronic engineers and manufacturers seeking cost-effective, high-performance connectors. Originating from China, this product combines quality, versatility, and availability, meeting diverse application requirements while maintaining competitive pricing at just 0.0001 per unit.

Customization:

Our Male Pin Header Connector, model LP-P079 from Loupeng, offers excellent customization services to meet your specific requirements. Manufactured in China and certified with ISO-9001:2000, this Dual Row Pin Header ensures reliable performance with a current rating of 1.0AMP or 3.0AMP and a dielectric strength of 1000 V AC minimum.

The Through Hole Pin Header is designed for durability, with a dielectric withstanding voltage of AC 500V and a processing temperature tolerance of 260℃ for 10 seconds. We provide flexible packaging options including Reel, Tube, Tray, and Polybag to suit your logistics needs.

With a minimum order quantity of 1000PCS and a competitive price of 0.0001 per piece, we guarantee prompt delivery within 7 to 10 days. Payment terms are convenient, accepting T/T and L/C. Our supply ability reaches up to 1,000,000PCS to support large-scale production demands.

Choose Loupeng’s Male Pin Header Connector for high-quality, customizable Dual Row and Through Hole Pin Header solutions tailored to your project specifications.
